Home > Electrical & Electronics > Inverter > Power Inverter > Under Input Voltage Transformer 500W Solar Inverter Price
Under Input Voltage Transformer 500W Solar Inverter Price
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ASEP
Model Number:
AP-500
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan / Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Short Circuit Protection Pure Sine Wave Power Transformer 500W InverterNegotiableMOQ: 1 Unit -
Over-Heat Protection Pure Sine Wave 500W Inverter TransformerNegotiableMOQ: 1 Unit
-
Over Load Protection Solar 500W Pure Sine Wave Power InverterNegotiableMOQ: 1 Unit
-
Dual Core Cpu 500W Off Grid Dc To Ac Solar Micro InverterNegotiableMOQ: 1 Unit
-
Led+Lcd Display Off Grid Solar Micro InverterNegotiableMOQ: 1 Unit
Place of Origin
Guangdong, China
Brand Name
ASEP
Model Number
AP-500
Output Power
1 - 200KW
Output Type
Single
Size
385*240*145mm
Weight
7KG
Input Voltage
145V~280V
Output Voltage
220V±10%
Type
DC/AC Inverters
Output Frequency
50Hz
Output Current
about 9 A
Under Input Voltage Transformer 500W Solar Inverter Price
| Item No. | AP-500 | AP-1K | AP-2K | AP-3K | AP-5K | |
| Series Name | Off-Grid Inverter | |||||
| Rated Capacity | 500W | 1KW | 2KW | 3KW | 5KW | |
| Input | ||||||
| DC Input Voltage |
Nominal DC input voltage |
12VDC | 24VDC | 48VDC | 48VDC | |
|
Backward noise current |
≤10% | |||||
| AC Input Voltage | AC input voltage | 145V-280V 50Hz | ||||
|
maximum input current |
7A | 12A | 18A | 35A | ||
| AC Output | ||||||
| Output Voltage | 220V±10% | |||||
| Output Frequency | 50Hz | |||||
| Output Waveform | Pure Sine Waveform | |||||
| Waveform Distortion | ≤5% | |||||
| Dynamic Reaction Time | ≤40MS | |||||
| Power Factor | 0.9 | |||||
| Protection Methods | ||||||
| Overload Capability | 120% Fullload lasting for 10S | |||||
| Overload protection | √ | |||||
| Short Circuit Protection | √ | |||||
| Functions | ||||||
| Invert Efficiency | ≥83% | ≥85% | ≥90% | ≥90% | ||
| Transfer Time | ≤6MS | |||||
| Rechage |
Intelligent Recharge will adjust automacticly according to the battery capacity. Maximum 12A. |
|||||
| Batteries Protection |
Automatic testing,Over discharge protection,Overcharge protection, Intelligent management |
|||||
| Physical | ||||||
| Shipping Weight | 7KG | 12KG | 24KG | 29KG | 43KG | |
| Shipping Width | 385MM | 385MM | 515MM | 515MM | 435MM | |
| Shipping Height | 240MM | 240MM | 383MM | 383MM | 220MM | |
| Shipping Depth | 145MM | 145MM | 245MM | 245MM | 430MM | |
| Display Monitor |
LCD(Standard),Displaying Utinity Power condiction, inverting condiction,load capacity and battery capacity |
|||||
| Environmental | ||||||
| Operating Temperature | 0℃~40℃ | |||||
| Operating Relative Humidity | 0%~90% Non Condencing | |||||
| Conformance | ||||||
| Regulatory Approvals | ISO9001 | |||||
| Standard Warranty | 1 YEAR | |||||
Features:
- 1. Pure sine wave Output, applicable in various field
- 2. More stable, safer industrial online system
- 3. CPU with dual core, Better performance.
- 4. Availability of wide range of input voltage, AVR available
- 5. Protection against overload, short circuit, over/lower voltage, over-heat
- 6. LED+LCD display, evident showing
- 7. Extended batteries group available for prolonging back-up time
- 8. Intelligent battery management with over-charge and over-discharge protection
- 9. Temperature controller adjusting cooling ventilation, reducing noise
- 10. High efficiency of transferring, diminishing energy loss, increasing stability
Details
Advantages
Product Advantages
1.Smart Mute System
Smart regulation working condition so noise below 40DB
2.LED+LCD display, evident showing
3.CPU with dual core, better performance
4.Pure sine wave output, applicable in various field
5. Available wifi module
Wifi module enables the inverter status to be monitored in remote real-time
After-Sales Service
After-sales service
A. Remote Technical Support (those with WIFI module installed);
With WIFI module installed, we can help you monitor the performance of your machine.
B. Free training and Consultancy
Apart from the user manual, free personnel training is offered at our factory.
C. 2% Back-up material for main parts is provided.
For order more than 100 pcs and above, we can provide 2% back-up for key parts of the machine.
D.One Year Warranty
