Over / Under Output Voltage Impact Resistance 250Kva Industrial Modular UPS
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ASEP
Model Number:
AIS250KVA
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan / Shenzhen Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Netwrok Equipments Low Frequency Online 40Kva Three Phase UPSNegotiableMOQ: 1 Unit -
Lcd Touch Screen Low Frequency Online 20Kva UPS PriceNegotiableMOQ: 1 Unit
-
Short Circuit Protection Low Frequency Online 300Kva UPS Hs CodeNegotiableMOQ: 1 Unit
-
Lcd Touch Screen Double Conversion Low Frequency Online 60Kva UPSNegotiableMOQ: 1 Unit
-
Hospital Vital Equipments Low Frequency Online 80Kva UPSNegotiableMOQ: 1 Unit
Place of Origin
Guangdong, China
Brand Name
ASEP
Model Number
AIS250KVA
Phase
Three Phase
Protection
Other, over / under input voltage, over / under output voltage, over-curren
Weight
1780KG~2300KG
Output Voltage
380VAC±1%
Type
On-line
Application
Other, Medium and small size data centre; Medium and small size industrial co
Over / Under Output Voltage Impact Resistance 250Kva Industrial Modular UPS
| Item No. | 100KVA | 120KVA | 160KVA | 200KVA | 250KVA | 300KVA | 400KVA |
| Series Name | Industrial Online Series | ||||||
| Rated Capacity | 80KW | 96KW | 144KW | 180KW | 225KW | 270KW | 360KW |
| Inverter | |||||||
| Input Phases | RST+L+N | ||||||
| Nominal Output Voltage | 380VAC±1% | ||||||
| Nominal Output Frequency | 50/60Hz±0.5%(Battery mode) | ||||||
| Power Factor | 0.8/0.9 | ||||||
| Frequency Stability (synchronized) | <±0.5 | ||||||
| Frequency Stability (non-synchronized) | <±2% | ||||||
| Crest Factor | 3:01 | ||||||
| Output Waveform | Sine Waveform | ||||||
| THD (Total Harmonic Distortion) | Linear load<3%;Non linear load<5% | ||||||
| Fluctuation Voltage for Unstable Load | <±4% | ||||||
| Transient Recovery Time | <10MS | ||||||
| On-Load Voltage | Balance:<±1% Unbalance:<±5% | ||||||
| Overload Capability | 120% overload lasting 30Mins,150% overload lasting 1min. | ||||||
| Inverter Efficiency, 100% on load | >93 | >95 | |||||
| Bypass | |||||||
| Input Phases | RST | ||||||
| Nominal Output Voltage | 300VAC±15% | ||||||
| Nominal Output Frequency | 50/60Hz±10% | ||||||
| Transfer Time | 0MS | ||||||
| Physical | |||||||
| Shipping Weight | 800KG | 980KG | 1300KG~1550KG | 1780KG~2300KG | |||
| Shipping Width (mm) | 900 | 1540 | 1420 | 1650 | |||
| Shipping Height (mm) | 1440 | 1570 | 1780 | 1920 | |||
| Shipping Depth (mm) | 1100 | 890 | 860 | 1250 | |||
|
Noise (within 1 m) |
53~68db | ||||||
| Cable Placement | bottom or back | ||||||
| Color | Black or White | ||||||
| System | |||||||
| Communication Interface | RS232, RS485,Dry contact,Intelligent slot | ||||||
| Cooling Method | Forced ventilation | ||||||
| Protection Level | IP20 | ||||||
| MTBF | 300,000 hours | ||||||
| Environmental | |||||||
| Operating Temperature | 0℃~40℃ | ||||||
| Operating Relative Humidity | 0%~80% | ||||||
| Operating Altitude | >1000M(1% Power dcreased in every 100M increased. Maximum 4000M) | ||||||
| Conformance | |||||||
| Regulatory Approvals | ISO9001 | ||||||
| Standard Warranty | 1 year | ||||||
Features:
ASEP’s Industrial Online uninterruptible power supplies are specially designed to support all kinds of precise instruments, large equipments data center and production machines etc. , preventing from any unstable power or interruption affecting their normal work performance.
- DSP control technique is applied;
- Data displayed on wide, clear and touch-sensitive LCD screen;
- Code setting available;
- ECO friendly design increases power efficiency up to 97%;
- Charging current can be adjusted manually
- Adaptability of 100% unbalanced load;
- Advanced technique design includes silicon controlled rectifier, static transfer switch, and output isolation;
- Protection against over/lower input voltage, over/lower output voltage, over-current, over-heat;
- N+X redundancy;
Details
Advantages
Product Advantages
1.Smart Mute System
Smart regulation working condition so noise below 50DB
2. Touch-sensitive LCD screen, Password Protection System
3. DSP control technique is applied
4. Available wifi module
Wifi module enables the UPS status to be monitored in remote real-time
After-Sales Service
After-sales service
A. Remote Technical Support (those with WIFI module installed);
With WIFI module installed, we can help you monitor the performance of your machine.
B. Free training and Consultancy
Apart from the user manual, free personnel training is offered at our factory.
C. 2% Back-up material for main parts is provided.
For order more than 100 pcs and above, we can provide 2% back-up for key parts of the machine.
D.One Year Warranty
If you have any questions, plz feel free to contact us.
