Home > Metallurgy, Mineral & Energy > Wear Resistant Material > Tungsten Carbide Glass Blade

Tungsten Carbide Glass Blade

Name: Tungsten Carbide Glass Blade
Brand: lihua
SKU: 119332035
Availability: InStock

Tungsten Carbide Glass Blade thumbnail-1

Tungsten Carbide Glass Blade thumbnail-2

Tungsten Carbide Glass Blade thumbnail-3

Tungsten Carbide Glass Blade thumbnail-4

Tungsten Carbide Glass Blade thumbnail-5

Tungsten Carbide Glass Blade thumbnail-6

US$ 8.00 - 8.00 MOQ: 10 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Hunan, China

Brand Name:

lihua

Model Number:

Customized

Contact Supplier Request Quote Chat Now

Zhuzhou Lihua Cemented Carbide Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhuzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hunan, China

Brand Name lihua

Model Number Customized

Alloy Specification 30UF

Particle 0.8

Product Description

Basic Info	Performance: Excellent Wear Resistance	Place of Origin: Zhuzhou China (Mainland)	Process Engineer: Adopt Advanced Technology
Model NO.: carbide inserts	Specification: According to Your Request, ISO9001 SGS	Business Type: Manufacturer	Application: Inserts, Cutting, Blades, Industries
Cer: ISO9001 SGS	Material: 100% Raw Materials	Origin: Zhuzhou, China (Mainland)	Name: Carbide Blades
Advantage: Over 20 Years Experience in This Line	Trademark: LIHUA

Applicable Machine	Tungsten carbide inserts for turning, milling, threading, grooving tool, cutting tools, etc.
Stock	For standard, have enough in stock
	For non-standard, need to be customized
Nonstandard order	Customize as request
Packing:	Can laser printing your logo and packing with your label
Coating:	CVD or PVD coating or as your require
Suitable for steel , cast iron , stainless steel etc materials

Different grades are available, such as K10, K20, YG8, YG6, P10, P20, YT15 ect.
ISO Grade	Grade	Density (g/cm³)	Hardness HRA	Application recommened
K05	YG3X	15.3	92	For finishing of cast iron non-ferrous metal
K10	YG6A	14.8	91.5	For drawing dies and wood wooking tools
K20	YG8	14.6	89.7	For drawing dies or milling of cast iron
M10	YW1	13	91	For semi-finishing and finishing of stainless steel
M20	YW2	12.9	90.5	For machining of train's wheel hubs
P10	YT15	11.3	91.5	For semi-finishing and finishing of stainless steel
P20	YT14	11.4	90.5	For semi-finishing and finishing of stainless steel
P30	YT5	12.8	89.5	For heavy duty rough tuming of steel

Grade	Density (g/cm₃)	Hardness(HRA)	T.R.S (N/mm₂)	Applications
YG8	14.6-14.9	≥89	≥2100	Suitable for the roughening of cast iron and light alloysand also for the milling of cast iron and low-alloy steel.
YG6X	14.6-14.9	≥92	≥1880	Good wear resistance, suitable iron alloy, copper alloy,glass, plastic, cardboard, hard rubber, wood processing,
FK10U	14.5-14.9	≥2100	≥92.5	Good abrasion resistance, good use of strength, suitable for chilled cast iron, non-ferrous metals and semi-finished cardboard, hard rubber, acrylic, wood processing, MDF, fiberboard, hardwood, plywood processing.
FK30U	14.3-14.6	≥2200	≥91.5	Good wear resistance, high flexural strength and bonding capability, suitable for processing high-temperature alloys,stainless steel and cardboard, hard rubber, acrylic, wood processing, MDF, fiberboard, hardwood, softwood, plywood processing..

Grade Recommendation of Tungsten Carbide Inserts
Grade	Applications
YBC151	High wear resistance of the matrix and MT-TiCN, thick Al2O3 and TiN coating.
YBC152	Thick TiCN and Al2O3 coating
YBC251	tough matrix of good edge security and MT-TiCN, thick Al2O3 and TiN coating.
YBC252	Tough matrix of good edge security and MT-TiCN, thick Al2O3 and TiN coating.
YBC351	Tough matrix of good edge security and MT-TiCN, thick Al2O3 and TiN coating.
YBG102	nc-TiAN coating and fine-grained matrix.
YBG202	nc-TiAN coating and fine-grained matrix.
YBG205	Added abrasion resistance and high temperature rare elements ultrafine TiAlN based nano-coating. High layer hardness and excellent resistance to high temperature provide effective protection for the cutting edge.
YBG302	nc-TiAN coating and flexible cemented carbide matrix.
YBM151	Special organizational structure and TiCN, thin Al2O3 and TiN coating.
YBM251	Good toughness and strength matrix and TiCN, thin Al2O3 and TiN coating.
YBM253	With the advance extra fine grain nanometer coating technology, match up with the high toughness gradient matrix.
YBD052	CVD coating(extra thick Al2O3 & thick TiCN), hard matrix.
YBD102	CVD coating (thick Al2O3 & thick TiCN) , hard matrix.
YBD152	CVD coating (thick Al2O3 & thick TiCN), hard matrix, it is anti-stripping.
YBD252	CVD coating (middle thick Al2O3 & thick TiCN), hard matrix.
YNG151	Uniform particle refining organizational ceramal alloy, homogenizing organizational & ring form phase structure, Strengthen bond phase,grain boundary composition design.
YD101	Fine particle hardness phase WC and bond phase Co.
YD201	Middle particle hardness phase WC and bond phase Co.

1,groove cutting tool, grooving and turning insertsYBG302 ZPGS0402-MG

2,parting inserts, carbide cnc parting and grooving tools, grooving and turning insertsYBG302 ZPGS0402-MG

3,cemented carbide inserts for cutting tools,cnc turning inserts,YD201 VNMG160404-PM

4,YD201 VNMG160404-PM,cnc carbide cutting tools, carbide indexable turning milling inserts

5,groove cutting tools,cnc carbide grooving tools,grooving inserts YBG302 ZTGD0404-MG

6,CCMT tungsten carbide tipped turning tool,tungsten carbide inserts for turning tools

7,CCMT tungsten carbide cermet cnc inserts for metal lathe cutting tools

8,ceramic turning inserts,cnc tnmg turning inserts YBC351 TNMG160404-DM

carbide indexable tnmg turning inserts YBC251 TNMG220408-DM

9,cemented carbide brazed tips

10,tungsten carbide cnc indexable insert for cnc machine

11,tungsten carbide cnc insert, CVD/PVD cnc insert,cnc cutter inserts

12,YG8 A320 cemented carbide brazed tips for making and periphery turning tools

13,YG8 k20 cemented carbide A325 tips for brazing

14,YG8 k20 cemented carbide brazed tips A330

15,YG8 cemented carbide brazed tips C306 for making parting tools and grooving tools

16,YW2 M20 tungsten carbide A320 tips for brazing

17,non-standard tungsten carbide welding inserts for customized available

18,Walter iso indexable carbide turning inserts CCGT/CCMT

19,Iscar tungsten carbide cnc carbide inserts/cemented carbide inserts for cutting tools

20,Iscar tungsten carbide CNC index carbide inserts coated with cvd/pcd

21,Kennametal tungsten carbide indexable insert for cnc machine

22,CCMT cemented carbide and cermet inserts for metal lathe cutting tools

Certifications

Detailed Images

Our Advantage

1) Business Type: Manufacturer, Factory.ISO9001:2008, SGS.Focus on Tungsten Carbide industry more than 20 years.
2) Advanced technology, HIP sintering and precision grinding to ensure the goods performance;

3) 100% Virgin materials;
4) Each product through the strict inspections and confirm to the requirements of the lab parameters;

5) OEM & ODM are welcomed;
6) Small order is acceptable;
7) Flexible payment terms (L/C,T/T, western union, etc);
8) Provide custom made service with customer's drawing; Other size could be offered by your requirements;
9) We make sure to provide you with the best solutions for your individual case. Whether standard items or non-standard items all available;
10) Fast delivery and high quality;
11) Best after-sale service.

Packing & Delivery

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	The normal package is carton box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

Other Tungsten Carbide Products in Lihua
Tungsten Carbide Plates Tungsten Carbide Strips Tungsten Carbide Wood Working Cutting Tungsten Carbide Sleeves Tungsten Carbide Nozzles/Spraying Tungsten Carbide Balls Tungsten Carbide Wire Drawing Dies Tungsten Carbide Rods/Bars/Tubes Tungsten Carbide End Mill Tool Holders Tungsten Carbide CNC Tool Rods Tungsten Carbide Rings Tungsten Carbide Sealing Rings/Rollers Tungsten Carbide CNC Cutting Inserts Tungsten Carbide Special Cutting Tools Tungsten Carbide Mining Tools Tungsten Carbide End Mill/Milling Tools/Drill Bits Tungsten Carbide Customized Parts

Company Brief Introduction
Zhuzhou Lihua Cemented Carbide Co., Ltd was established in 1990, Based depend on good production advantage, and company with produce, research and development, sales, technical service together that have many rich production experience of the tungsten carbide products. Also have strong scientific research and development team and technicians, advanced quality inspection division, senior engineer, etc of the tungsten Carbide production. Our company mainly products such as carbide rod& tubing product, carbide strips &plates, carbide bars, carbide saw blade, carbide end mills, carbide drill bits, Carbide welding inserts, carbide CNC inserts, carbide woodworking tools, tungsten carbide powder, some non-standard tungsten carbide products and different other various type of the tungsten carbide products etc. We have independent developmented YS series of tungsten carbide grade that the grade belong the micro hole grain of tungsten carbide, good abrasion resistance, impact resistant capability is strong, affinity resistant capability is strong that also has good heat conduction performance and so on characteristic. Lihua is committed to the principle of "customer first, fast delivery and good after-sale service ". If you have any questions and any demand of tungsten carbide, please contact us without any hesitation. We promise you not offering only our qualified products, but also designing, prompt delivery, the most competitive prices and all solution.
