gabion mattress/gabion box

Specifications

gabion box:
Mesh Type: Double twisted hexagonal
holes size: 6x8cm, 8x10cm, 8x12cm, 10x12cm





Galvanized & PVC coated gabion box/Gabion basket/Gabion mattress/ Heavy hexagonal wire netting/reno mesh

Woven style:

Material:(1)Hot dip galvanized wire
Heavy zinc-coated wire(EN10244-2  240g/m²)
(2)Pvc coated wire(Pvc thickness:0.38-0.5mm)
(3)Galfan wire



Mesh Type: Double twisted hexagonal

Gabion mesh wire dia: 2.0-3.5mm ,
Mesh size: 6x8cm, 8x10cm, 8x12cm, 10x12cm etc.

Gabion size: can be design as per the clients' requirement.
(normal size:1.5x1x1m, 2x1x1m, 3x1x1m, 2x1x0.5m, 4x1x1m, 3x2x0.23m, 4x2x0.23m)



Gabion box is made by heavy hexagonal wire mesh which is also named gabion baskets.

In order to reinforce gabions configurable intensity, all of the face halftone side adopt more thick ntrol and lead to water or flood, water and soil protection, keep off dust wall.



Normal aperture sizes(mm)              The inner wire diameter/outer wire diameter

60*80                                            2.0mm/3.0mm-2.8mm/3.8mm

80*100                                           2.2mm/3.2mm-3.0mm/4.0mm

100*120                                         2.4mm/3.4mm-3.2mm/4.2mm

120*150                                         2.7mm/3.7mm-3.5mm/4.5mm



welded stype:



welded gabion mesh/gabion box/gabion basket



Material:carbon steel wire

types: electro galvanized or hot dipped galvanized

Wire dia:2.0mm-6.0mm

Mesh openning:50*50mm,50*100mm, 80*80mm ,80*100mm,100*100

Sets of gabion steps 1m to 2m wide



Package:often folded, then put them together, then load on the pallet.

Delivery Time: within15 days, sometimes as per the stock of our factory



Welded mesh gabions are faster to erect and do not need tensioning. Welded Wire Gabions are made from rigid, lightweight, galvanized steel mesh that allows for machine filling, holds the alignment of the face.
