Home > Electrical & Electronics > Relay & Contactor > Contactor > Cjx2-d95/lc1-d95 AC Magnetic Contactor
US$ 1 - 30
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Hvacstar or OEM
Model Number:
LC1-D95 AC magnetic contactor, LC1-D95 AC magnetic contactor
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
For Telemecanique Magnetic LC1-D AC ContactorUS$ 2.01 - 3.69MOQ: 1000 Pieces -
LC1-D4011 Magnetic AC ContactorUS$ 2.01 - 3.69MOQ: 1000 Pieces
-
For Telemecanique Model LC1-D AC ContactorUS$ 2.01 - 9.69MOQ: 1000 Pieces
-
CJX2-E06 LC1-E06 AC ContactorUS$ 2.01 - 9.69MOQ: 1000 Pieces
-
SA-1P-40A-277VAC Definite Purpose Contactor ac ContactorUS$ 3 - 5MOQ: 1000 Pieces
Place of Origin
Anhui, China
Brand Name
Hvacstar or OEM
Model Number
LC1-D95 AC magnetic contactor, LC1-D95 AC magnetic contactor
Electricity Type
Other, AC, AC
Number of Pole
Other, 3, 3
Phase
Other, 3, 3
Main Circuit Rating Voltage
1000v
Main Circuit Rating Current
Other, 49
Specifications
LC1-D(JX2) series AC contactors are suitable for frequency 50/60Hz rated insulation voltage up to 1000VProduct details
LC1-D(JX2) series A.C. contactors are suitable for frequency 50/60Hz,rated insulation voltage up to 1000V,rated operation current 9-330A under AC-3 duty. It is mainly used for making/breaking electric circuits at a long distance & for frequent starting/stopping & controlling A.C. Motors. It is used in combination with thermal relay to compose a magnetic motor starter.
Specification:
| Type | LC1-D09 | LC1-D12 | LC1-D18 | LC1-D25 | LC1-D32 | |
| Rated working current (A) | AC3 | 9 | 12 | 18 | 25 | 32 |
| AC4 | 3.5 | 5 | 7.7 | 8.5 | 12 | |
| AC3 capacity of phase 3 squirrel-cage motor AC3(kW) | 220/230V | 2.2 | 3 | 4 | 5.5 | 7.5 |
| 380/400V | 4 | 5.5 | 7.5 | 11 | 15 | |
| 415V | 4 | 5.5 | 9 | 11 | 15 | |
| 440V | 4 | 5.5 | 9 | 11 | 15 | |
| 500V | 5.5 | 7.5 | 10 | 15 | 18.5 | |
| 660/690V | 5.5 | 7.5 | 10 | 15 | 18.5 | |
| Rated heat current (A) | 20 | 20 | 32 | 40 | 50 | |
| Electrical life | AC4 x 104 | 20 | 20-15 | 20-7 | 15-7 | 15-7 |
| AC3 x 106 | 2 | 2 | 2 | 2 | 2 | |
| Mechanical | 20 | 20 | 20 | 20 | 20 | |
| Number of the contact | 3P+NO | |||||
| 3P+NC |
| Type | LC1-D40 | LC1-D50 | LC1-D65 | LC1-D80 | LC1-D95 | |
| Rated working current (A) | AC3 | 40 | 50 | 65 | 80 | 95 |
| AC4 | 18.5 | 24 | 28 | 37 | 44 | |
| AC3 capacity of phase 3 squirrel-cage motor AC3(kW) | 220/230V | 11 | 15 | 18.5 | 22 | 25 |
| 380/400V | 18.5 | 22 | 30 | 37 | 45 | |
| 415V | 22 | 25 | 37 | 45 | 45 | |
| 440V | 22 | 30 | 37 | 45 | 45 | |
| 500V | 22 | 30 | 37 | 55 | 55 | |
| 660/690V | 30 | 33 | 37 | 45 | 45 | |
| Rated heat current (A) | 60 | 80 | 80 | 125 | 125 | |
| Electrical life | AC4 x 104 | 10-7 | 7 | 7-6 | 7-5 | 7-5 |
| AC3 x 106 | 2 | 2 | 1.6 | 1.6 | 1.6 | |
| Mechanical | 20 | 20 | 20 | 10 | 10 | |
| Number of the contact | 3P+NC+NO |
Outline and installation dimension:
