It is suitable for the press fitting and stretch forming of metal and plastic products as well as the movements of coining and overprinting.
It mainly applies to the fields of machine tool, engineering machinery, bearings, washing machine, automobile parts, motor components and powder metallurgy.
It is suitable for the molding of plastic products, such as DMC and BMC.
The machine, with a high degree of automatization, is particularly suitable for the mass production of parts. And it can be used as assembly line with several such equipments.
Name |
Model No. |
Specification |
Unit |
Parameter |
|
Y27 Four-column deep drawing hydraulic press |
Y27-400T |
Nominal Pressure |
KN |
4000 |
|
Max. pressure of liquid |
Mpa |
25 |
|||
Max. opening height |
mm |
1200 |
|||
Max. slide stroke |
mm |
800 |
|||
Cushion force |
kN |
2000 |
|||
Cushion stroke |
mm |
300 |
|||
Dia. of four columns |
mm |
140 |
|||
Cushion size |
See attached drawing |
||||
Upper-table Size |
F.B. |
mm |
1200 |
||
L.R. |
mm |
1240 |
|||
Lower-table Size |
F.B. |
mm |
1200 |
||
L.R. |
mm |
1240 |
|||
Worktable Height |
mm |
1250 |
|||
Speed of |
Idle speed |
mm/s |
200 |
||
Working speed |
mm/s |
15 |
|||
Return speed |
mm/s |
100 |
|||
Overall Dimensions |
L.R. |
mm |
2025 |
||
F.B. |
mm |
1850 |
|||
Height above floor |
mm |
3700 |
|||
Motor Power |
KW |
22 |
|||
Voltage |
380V, 50Hz, 3 Phase |
||||
Operating Temperature |
℃ |
0-40 |
|||
Total Weight(Approx) |
Ton |
21 |
|||
|
|||||
