ELECTRIC SURFACE GRINDING MACHINE MD820

ELECTRIC SURFACE GRINDING MACHINE MD820 thumbnail-1
ELECTRIC SURFACE GRINDING MACHINE MD820 photo-1
US$ 3,000 - 3,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
SIMEX
Model Number:
MD820
Contact Supplier Request Quote Chat Now
Shaanxi Simex Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name SIMEX
Model Number MD820

Specifications

1.table size :480X200MM
2Adopt the exceeding precise class7(P4 level) ball bearing for spindle.

ELECTRIC SURFACE GRINDING MACHINE MD820 SPECIFICATION:


1,Adopt the exceeding precise class7(P4 level) ball bearing for spindle.
2,The transmission of table can be dynamical and manual





Technical Parameters

Unit

MD820

piece to be Ground ( L×W×H)

mm

520×220×450

Max. Grinding Length

mm

530

Max. Grinding Width

mm

220

Distance From Table Surface To Spindle Center

mm

450

Slide way



V-type rail with Steel-ball

V-type rail with Steel-ball

Kg

200

Table Size (L×W)

mm

480×200

Number of T -Slot

mm×n

14×1

Speed OF Working Table(Stepless)

m/min

3-20

Cross Feed On Handwheel

mm

0.02/Graduation 2.5/revolution

Auto-feed in transverse (Stepless)

mm/min

0-5

Rapid feed in transverse

r/min

150

Wheel Size (dia.×width×bore )

mm

200×20×31.75

Spindle Speeds

50Hz

rpm

2850



30-6000

Spindle Motor

Kw

1.1

Auto-feed motor in transverse

Kw

0.2

Auto-feed motor in longitudinal

Kw

0.2

Machine Size (L×W×H)

mm

1680×1140×1760

Packing Size (L×W×H)

mm

1140×1250×1940

Gross,Net

T

O.817, 0.717
