Specifications

1.automatic pabel printing machine
2.4 colors
3.for fabric & simple adhersive printing



Automatic Label Printing Machine YTP4100 specification:

YTP 4100 is designed for fabric & simple adhesive printing in roll form. For matorials like nylon taffota and polyester satin & adhesive paper etcs.Automaically in line with printing & die cutting in one process,(only 3 colors with die cut attached).This letter press system is suitable for photopolymer plate,zinc,and photo-engravers plate printing.It is the desirable machine for ribbon,simple adhesive, bar-code & letter pringting etc. YTP 4100B is specially for double sides printing in one process.Speed must less than 2500pcs/hour to allow drying for printed area during reverse process

Model	YTP 4100	YTP 4100B
MAX.Printing Width	100mm
MAX.Printing Length	180mm ( 1 - 2 colors) 90mm ( 3 - 4 colors)
Printing speed	50-5000imp/h
Front&back Printing	Only front	Front&back Printing
power/voltage	1.5KW/220V	2.5KW/220V
Size L*W*H	1450*850*1450mm
Weight	600KG	620KG
