Milk Candy Machine
US$ 10,000 - 105,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Model Number:
QH400
Application:
Chocolate
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shanghai, China
Model Number
QH400
Application
Chocolate
Specifications
milk candy machine1.two/three -color candy,filled hard candy,mint candy etc
2.Simens PLC cont
milk candy machine
GENERAL DESCRIPTION:
QH150/300/450/ 600 hard candy depositing line is a compact unit which can continuously produce various kinds of hard candies under a strict sanitary condition. It is also an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.
STRONGPOINTS:
* PLC /computer process control available;
* An LED touch panel for easy operating;
* The production capacity from 150 kgs/h to 450kgs/h;
* Optional (mass) flowing controlled by Frequency inverters ;
* In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid(milk); Dosing pumps for the automatic injection of colors, flavors and acids;
* One set of extra chocolate paste injection system for making chocolate-central candies; "two/three-color striped depositing","two /threecolor double layers depositing", "central filling", "clear" hard candies and etc. can be made.
* Moulds can be made according to the candies samples provided by the customer."
PARAMETERS:
MODEL |
QH150 |
QH300 |
QH450 |
QH600 |
Capacity(kg/hr) |
150 |
300 |
450 |
600 |
Max candy weight |
6g |
6g |
6g |
6g |
Depositing speed |
55-65n/min |
55 |
65n/min |
55 |
Compressed air requirement |
0.2m³/min,
0.4-0.6Mpa
|
0.2m³/min,
0.4-0.6Mpa
|
0.2m³/min,
0.4-0.6Mpa
|
0.2m³/min
,0.4-0.6Mpa
|
Working condition |
Temp:20-25
Humidity:55%
|
Temp:20-25
Humidity:55%
|
Temp:20-25
Humidity:55%
|
Temp:20-25
Humidity:55%
|
Total Power |
18kw/380V |
27kw/380V |
34kw/380V |
38kw/380V |
Total Length |
15m |
17m |
17m |
20m |
Total Weight |
3500kg |
4000kg |
4500kg |
5000kg |
DIRECT MANUFACTURER FOR FOOD MACHINERY
REAL PHOTOS IN OUR MANUFACTURING WORKSHOP:
PHOTOS WHILE WORKING:
CANDY SAMPLES FROM THE LINE :
(FOR DIFFERENT SHAPES AND SIZE, JUST CHANGE THE MOULDS)
PARTS OF OUR PRODUCTS ALREADY GOT THE CE CERTIFICATE:
STRONG SEAWORTHY WOODEN PACKING :
90% OF OUR PRODUCTS ARE EXPORTED , GOOD QUALITY AND IN-TIME AFTER SALE SERVICE ARE THE STRONGPOINTS OF OUR COMPANY.
QINHUI-- PROFESSIONAL MANUFACTURER FOR FOOD MACHINEY.
