Help CenterAutomatic Liquid Packing Machine/seal the PE Film Precisely/good Quality
Related Products
-
Automatic Compound Film Liquid Packing MachineNegotiableMOQ: 1 Set -
Sachet/pouch/liquid Filling Machine/PE Bags Filling MachineNegotiableMOQ: 1 Set
-
Automatic Packaging Machine/pouches Filling Machine/NegotiableMOQ: 1 Set
-
Sachet/pouch/liquid Water Filling Machine Automatic Packaging MachineNegotiableMOQ: 1 Set
-
Sachet/pouch/liquid Water Filling MachineNegotiableMOQ: 1 Set
Main functions
The machine has sensor tracing function, so it can seal the PE film precisely. The machine can pack kinds of non-carbonated liquid material widely, especially source, vinegar, syrup, beverage, confect beverage(also the cold beverage makes ice bag), sweet condensed milk, soy milk, mineral water, greese bean curd and liquid sack.
Technique parameters
3.1. Yield capacity 1500~1800B/H
3.2. Packing volume 100~500ml/Bag
3.3. Filling precision ±1%
3.4. Film width 240mm or 320mm(optional or choose others)
Power Moter: single phrase,three phrases 1.1KW
Vertical hot seal: 0.3KW Horizontal hot seal: 0.5KW
UV sterilizer lamp15KW
3.5. Power supply AC220V/Hz or AC380V(three phrases)
3.6. The weight of the machine 360kg
3.7. Dimension(L×W×H) 750*700*1700mm
D,Function
1,sack molding 2,UV sterilizer 3,Vertical cutting hot seal
4,Date composed 5,beeline tows sack 6,ration filling
7,Horizonal cutting hot seal 8,Cutting sack 9,count automatically
Main Technological Data | ||
Model |
YF-1000 |
|
Production Capacity |
1500-1800BAGS/H |
|
Filing Range |
100-500ML(1000MLcan be customized) |
|
Voltage |
AC220V/50HZ AC380V |
|
Paper-offering Motor |
250W/220V |
|
Power of Hot Sealing |
vertical sealing |
300W 500W |
horizontal sealing | ||
Main Motor Power |
370W/380V/220V |
|
Overall Dimension |
750×700×1700MM |
|
Weight |
360KG |
|
Num. |
Sign |
Qty. |
Item |
Spec. and model |
Memo |
1 |
FD |
2 |
screw fuse |
RFI-10A |
|
2 |
XWK |
2 |
Process switch |
JFXK1-441 |
|
3 |
K |
4 |
switch |
MK211B/n81 |
|
4 |
ZZ |
1 |
UV lamp tube |
ZWS series 15W/220V |
|
5 |
JC |
1 |
AC Contactor |
CJ46-9 |
10A/220V |
6 |
JJ |
1 |
electromagnetic counter |
LFC-5 |
AC220V |
7 |
TE |
2 |
temperature controller |
TE-2601 |
|
8 |
RE |
2 |
thermocouple |
E,EA2 |
(a set) |
9 |
SRM3 |
1 |
Tubiform Electro-heating element |
Φ20 stainless stell shell |
300W(vertical seal) |
10 |
SRM5 |
1 |
Tubiform Electro-heating element |
Φ20 stainless steel shell |
500W (horizontal seal) |
11 |
D |
|
motor |
0.37KW/1.1KW |
|
12 |
Q |
1 |
Electricity-leakage protector |
DZL18-20 |
|
Our company
Guangdong Yue Feng Drinking Water Equipment Co., Ltd is a high-tech enterprise specialized in water treatment project. Our company is located in Jiangmen city Guangdong province, about 80 KM away from Guangzhou Baiyun international Airport. Our company specializes in all kinds of water equipment, such as Ro pure water equipment; automatic filling machine equipment, automatic vending machines, seawater desalination equipment, household water filter and many related equipment. Our products are sold to all over the world, for example, America, Australia, Africa, India, Southeast Asia, Dubai, Middle East etc.
