water bottling plant
- 100 Set / Sets per Month
- Jiangmen
- T/T
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage, Other, Beverage, water | Packaging Type: | Bottles |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220-380v | Place of Origin: | Guangdong, China | Brand Name: | Yue Feng |
Model Number: | YF24-24-8 |
Product Description
rinsing, filling, capping three in one machine
YF18-18-6 type PET bottle rinsing/filling/capping three in one machine was studied and developed by our company combined international advanced normal pressure filling technique and our own technique, it is suitable for filling pure water and mineral water. The machine was adopted conveying way of clamping bottle neck, only need to change a little spare parts so that it is suitable for various bottle shape, stable conveying, normal pressure filling.
1. frame of the machine made of structural steel, stainless steel 304 surface, stainless steel 304 frame mount, supported feet can be adjusted.
2.conveying system adopts star wheel, stable conveying, stainless steel conveying chain, less bottles out of shape.
3.head of washing bottle clamp is 24pcs, stainless steel 304 underpan rinsing piping, rinsing water filtration system.
4.head of filing valve is 24pcs, all the parts touched with water are made of stainless steel 304. Internal surface are polishing treated. Stainless steel return pipes, no dead angle.
5.head of capping is 8pcs, capping head adopted magnetism torquer, convenient adjustment of torquer, can setup the size of torquer according to actual production requirement.
Dynamical system
1.main motor and reducer casing, with frequency conversion speed regulation, every motion part is gear drive, operation stable, every bottle conveying star wheel is engineering plastics component, with safety protection facility.
2.PLC, frequency converter, relay, optoelectronic switch, inductive switch relay element, touch screen operation panel, imported pneumatic components.
Main parameter
1. Model: YF18-18-6
2.capacity: 4000-6000B/h (250ml, 500ml, 1000ml)
3.air source pressure: 0.4~0.6Mpa
4.air required: 0.3M3/min
5.washing bottle water pressure: 0.2-0.25Mpa
6.capacity of pure water washing bottle: 1T/h ( MAX. adjustable)
7.filling mode: normal filling
8.main motor power: 3KW
9.total capacity of motor: 4.5kw
10.related voltage: 380V 50Hz
11.weight: 3T
12.size: 2480×1960×2250mm
13.the machine includes: prior 3 meter wind-sent system, auto caps inserted machine, auto caps sorter device, post bottles conveyor belt 4 meters.
Othere capacity our factory can manufacture:
Model: | YF12/12/4 | YF16/12/6 | YF18/18/6 | YF24/24/8 | YF32/32/10 |
Heads of washing filling sealing | 12-12-4 | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-10 |
Production Capacity:500ml(B/h) | 3000 | 4000 | 6000 | 10000 | 12000 |
Suitable Bottle Standard:(mm) | φ=50-100mm, H=150-300mm, 330-1500ml | φ=50-100mm, H=150-340mm, 330-1500ml | φ=50-100mm, H=150-340mm, 330-1500ml | φ=50-100mm, H=150-340mm, 330-1500ml | φ=50-100mm, H=150-340mm, 330-1500ml |
Suitable cap type | plastic screw | plastic screw | plastic screw | plastic screw | plastic screw |
Filling Pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 |
Motor power | 2.2 | 2.2 | 3.0 | 3.0 | 4.0 |
Filling Temperature: | Room temperature | Room temperature | Room temperature | Room temperature | Room temperature |
Overall dimension(L×W×H(mm) | 2450×1450×2300 | 2400×1670×2350 | 2470×1970×2350 | 2865×2170×2350 | 4000×2570×2500 |
Total weight: (kg) | 2500 | 2500 | 3000 | 4000 | 5000 |
