Hot sell best price multi level long span heavy duty double side cantilever warehouse rack , storage rack (YB-WR-C43)
Specification:
Cantilever Racking is an ideal solution for storing long or heavy items.
double side cantilever warehouse racking
Description: single-sided/double-sided metal cantilever racking is designed to save space by efficiently storing long lengths of materials such as tubing, pipes and lumber. The cantilever metal storage rack offers flexibility to custom fit applications. The metal storage racks feature unique bolt-together construction. Individual components for these racks are sold separately.
Capacity: Cantilever uprights feature a capacity per side of up to 11,950 kg.
Construction: Cantilever metal cantilever racking features steel construction.
Color: RAL color Powder coated for option, we can also make hot dipped GAL suit for outdoor storage .
| H-Column Upright (H200*100) | Upright Capacitis in KG | ||||||||||||||||||||||||||
| Arm Length | |||||||||||||||||||||||||||
| Column Height | 600mm | 900mm | 1050mm | 1220mm | 1500mm | ||||||||||||||||||||||
| 3000 | 4860 | 3730 | 3510 | 3300 | 2550 | ||||||||||||||||||||||
| 4000 | 4830 | 3700 | 3350 | 3000 | 2500 | ||||||||||||||||||||||
| 4780 | 4800 | 3670 | 3320 | 2970 | 2490 | ||||||||||||||||||||||
| 5385 | 4750 | 3620 | 3270 | 2920 | 2440 | ||||||||||||||||||||||
| 6000 | 4700 | 3570 | 3220 | 2870 | 2390 | ||||||||||||||||||||||
| H-Column Upright (H250*125) | Upright Capacitis in KG | ||||||||||||||||||||||||||
| Arm Length | |||||||||||||||||||||||||||
| Column Height | 600mm | 900mm | 1050mm | 1220mm | 1500mm | ||||||||||||||||||||||
| 3000 | 8350 | 6550 | 5950 | 5350 | 4550 | ||||||||||||||||||||||
| 4000 | 8300 | 6500 | 5900 | 5300 | 4500 | ||||||||||||||||||||||
| 4780 | 8300 | 6500 | 5900 | 5300 | 4500 | ||||||||||||||||||||||
| 5385 | 8250 | 6450 | 5850 | 5250 | 4450 | ||||||||||||||||||||||
| 6000 | 8200 | 6400 | 5800 | 5200 | 4400 | ||||||||||||||||||||||
| H-Column Upright (H300*150) | Upright Capacitis in KG | ||||||||||||||||||||||||||
| Arm Length | |||||||||||||||||||||||||||
| Column Height | 600mm | 900mm | 1050mm | 1220mm | 1500mm | ||||||||||||||||||||||
| 3000 | 11950 | 9550 | 8700 | 7850 | 6750 | ||||||||||||||||||||||
| 4000 | 11900 | 9500 | 8650 | 7800 | 6700 | ||||||||||||||||||||||
| 4780 | 11900 | 9500 | 8650 | 7800 | 6700 | ||||||||||||||||||||||
| 5385 | 11850 | 9450 | 8600 | 7750 | 6650 | ||||||||||||||||||||||
| 6000 | 11800 | 9400 | 8550 | 7700 | 6600 | ||||||||||||||||||||||
ARM Loading capacity see following :
| Arm Type | Arm Capacities in KG | ||||||||||||||||||||||||||
| Arm Length | |||||||||||||||||||||||||||
| 600mm | 900mm | 1050mm | 1220mm | 1500mm | |||||||||||||||||||||||
| I Beam (100*68) | 1610 | 1070 | 910 | 790 | 640 | ||||||||||||||||||||||
| I Beam (100*68) | 1740 | 1470 | 1280 | 980 | |||||||||||||||||||||||
| Square Pipe (100*50*2.5) | 960 | 640 | 540 | 470 | |||||||||||||||||||||||
| Square Pipe (100*50*3.0) | 1130 | 750 | 640 | 550 | 420 | ||||||||||||||||||||||
Board in carton, upright and beam bubble foam of double side cantilever warehouse rack
Please inform us the listed information in your inquiry of warehouse double side cantilever rack system, so we can better quote to you :
1) AUTOCAD drawings of your warehouse (If have rack position in drawing it is better). We can design your racking system position for free according to your requirements.
2) Size of your warehouse?
3) Width, depth of shelving?
4) Height of warehouse rack system?
5) How many bays you want?
6) How many layers of each set / bay?
7) Loading capacity of each layer?
8) RAL color you want.
We also can provide rack like wire rack, plate rack, pallet rack , slective pallet rack, drive in pallet rack, multi-level rack, attic shelves, steel platform shelf, mezzanine rack, cantilevel rack, light duty rack, heavy duty rack, medium duty rack etc.
Introduction of our factory : Suzhou Youbang Commercial Equipment Co.,Ltd is build from 1999, which is one of the biggest leading professional manufacturer of supermarket equipments , storage equipments and airport trolley. Such as the supermarket shopping trolley & supermarket shopping cart , wire shelving and rack, supermarket shelving, warehouse rack & double side cantilever warehouse rack, aluminum alloy airport luggage trolley, roll container, wire cage, wire container etc.
We export goods to many area and country like USA, English, Germary, Australia, Middle east area, South Africa, South amercia area, Asian area etc. And as our business devolop so in 2007 we opened SUZHOU HUIDOU IMP&EXP. CO.,LTD to make our business to all over the world.
Our company was integrating development and production together ,employs more than 200 workers,Through the efforts of our entire staffs,we have become a strong supermarket and warehouse equipment manufacturer in china. On the side,ASHIYI people still have continuously tried to improve product quality, Introducing the advanced machine to make 100% sure quality. So far we have develop to be have 4 factories,Shopping carts factory, airport trolley factory, shelf factory,wire rack factory.
Our company regards " Reasonable prices with satisfying quality,efficient production time , good after-sales service"as our tenet. We hope to cooperate with more customer for mutual development and benefits.
We export warehouse vertical racking systems to many countries like USA, Australia, French, Middle east area, Africa countries, South Amercian countries etc.
Welcome potential buyers to contact us, sincerely hope to enter into long-terms and steady business relations with you!
FREQUNT QUESTION ANSWER ABOUT WAREHOUSE CANTILEVER RACK
1. What makes us different from others?
1) Our Excellent Service
For a quick, no hassle quote just send email to ours
We promise to reply with a price within 24 hours - sometimes even within one hour.
If you need an advice, just call our export office at 0086-0512-52302086, we will answer your questions immediately
2)Our quick manufacturing time
For Normal orders, we will promise to produce within 25 days.
3)Our Safty Design
Our Storage System is manufactured in a world class facility, designed to produce equipment of the highest quality that will deliver superior "life-cycle" value at a competitive price. They are the more stringent and industry respected standards of Europe.
4)Our Special Export Design
We pay very much attention to the export packages. We have plastic clips on the beams to protect the beams from surface damage in the transportation, We have got the whole uprights wrapped with transparent plastic film. You will find more details which show about our considerate.
5)Our Warranty
The High Standards in the Design and Manufacturing of its pallet rack systems enables us to support its products with a limited 2-Year Warranty, the Longest Manufacturer's Warranty. But the goods usually will use more than 10 years
