HUAWEI VPC600 VPC620 1080p 50/60fps HD Video Camera VPC600 VPC620-12X VPC620-4X
Ultra-HD video camera works with Huawei HD Series endpoints to provide 1080p 60fps high-definition video.
1080p 60fps HD CMOS
12x optical plus 4x digital zoom, 72° viewing angle
Inverse installation, setting button, LCD display
One cable for power and signal with control and media
3G-SDI for extra-long video transmission (only for VPC620)
Model |
HUAWEI VPC600 |
|
Lens | ||
Lens specifications |
2-megapixel and 1/3-inch CMOS imaging chip |
|
Video output pixels |
1080p @ 50/60 fps,1080i @ 50/60 fps,1080p @ 25/30 fps, 720p @ 50/60 fps |
|
Video | ||
Zoom |
HUAWEI VPC600/VPC620-12X: 12x optical plus 4x digital |
|
Focal length |
HUAWEI VPC600/VPC620-12X: f = 3.9 to 46.8mm |
|
Lens Aperture (F#) |
F1.8 |
|
Maximum horizontal field of view |
72º |
|
Maximum Vertical field of view |
44.5º |
|
Pan/Tilt range |
Pan: +/-100º |
|
Pan/Tilt speed |
Minimum pan and tilt: 2º/s |
|
Min. illumination |
2 lux (50 IRE, F1.8) |
|
Signal Noise Ratio (SNR) |
59dB |
|
Shutter speed |
1/25~1/10000 seconds |
|
White balance (WB) |
Automatic and manual |
|
Number of preset positions |
20 |
|
Image Mode | ||
Image Mode |
Standard, bright, warm |
|
Automatic adjustment | ||
Auto White Balance (AWB), Auto Exposure (AE), Auto Focus (AF) | ||
Special Functions | ||
Inversion support, IR receiver , Software update locally and remotely | ||
Input voltage |
100–240V AC 50-60Hz |
|
Working frequency |
12V DC |
|
< 20W |
||
Physical characteristics | ||
Ambient temperature |
0ºC to 40ºC |
|
Dimensions |
Camera dimensions: 234 mm x 163 mm x 157 mm |
|
Weight |
Net weight: about 1.5 kg |
|
Hardware interface specifications | ||
Interface Type |
Quantity and Description |
Standard Compliance |
Video output |
1×HD-VI (DVI & YPbPr) |
DVI1.0/YPbPr |
1× 3G-SDI(Only for VPC620) |
SMPTE-424M |
|
Communication control input |
1 ×RS-232C |
EIA-232-B |
About the Distribution:
As a golden distributor of HUAWEI, all of HUAWEI prodcucts from Polytrade/Sandes Technology are 100 % Original and Brandnew unless per clients’ requests; customers could claim 10time cost if you find we offer used or fake products. We offer one year warranty for all on-display products.
The HUAWEI products by us are whole series of hot-sell products, and if you did not find what you need on alibaba web, please contact us via sales[at] to gain supports.
Products Photos:
