Emerson PS48600-3B/2900-X2 X8 X9 X10 NetSure701CC9 DC Power System Emerson M522S R48-3200e R48-2900U
PS48600-3/2900 Power System is a highly reliable and DSP full digital controlled communication power system with high power density and high performance.
Designed for addressing the global customer demands. PS48600-3/2900 comes in 2m cabinet, including 12 rectifiers, with total capacity of 600A. This product has such merits as high efficiency, high reliability, ultra-low EMI and swift maintenance, fully meeting the -48V DC power requirements of medium-large mobile communication base stations, medium exchanges, transmission relay stations, micro-wave communication stations, and satellite communication stations.
The PS48600-3/2900 and PS48400-3/2900 DC power systems use digital signal processing (DSP) technology, completely meeting the demands of customers worldwide for high reliability, high efficiency, and high performance.The high-efficiency, high-reliability, super-low radiation rectifier of the systems is easy to maintain. It also fully meets -48VDC power demands of telecom networks.
System Model
2m-high cabinet has the following models:
- PS48600-3B/2900-X2
- PS48600-3B/2900-X8
- PS48600-3B/2900-X9
- PS48600-3B/2900-X10
Rectifier - R48-3200e R48-2900U
- CE and UL certified
- Wide input voltage range: 80 ~300Vac
- Input voltage frequency range: 45 ~65Hz
- Wide operating temperature range: -40°C ~+70°C (derated output at +45°C above)
- Relative humidity: ≤90%RH
- Altitude: ≤2000m
- Efficiency: 91%
- Power factor: 0.99
- Weight: 2.0 kg
Controller module – M522S
- Maximum 48 modules can be managed through CAN
- Smart battery management
- PLC available
- Alarm and maximum 200 alarm messages can be recorded
- 8 groups of alarm dry contact output
- RS232/Modem communication available
- Multi-language operational interface
AC distribution
One way or two way 100A mains input able to withstand up to 40KA surge impact.
DC distribution
With battery low-voltage and load low-voltage disconnection protection, the fuser or circuit breaker can be flexibly configured for the DC output.
Applications
- 2G, 3G mobile base stations
- Medium exchanges, rural telecom networks and access networks
- Transmission relay stations
- Microwave/satellite communications stations
Features
- Rectifier module adopts DSP technology with efficiency up to 93% and power density of 15.8W/in3
- In compliance with international standards such as CE and applicable for residential environment
- Wide input voltage range (85 to 90Vac), adaptable to poor electric power
- Rectifier module can operate in an environment of 65
- Rectifier ID identifying function, convenient for customer assets management
- Digitized current sharing technology with high stability and precision up to 3%
- Intelligent battery management function that expands lifetime
- Complete AC, DC and signal port lightning proof
- Highly intelligent in monitoring and remote control
- Hot-swap and online maintenance
Benefits
- Rectifier module adopts DSP technology power density up to 15.8W/in3
- Wide input voltage range (85 to 290Vac), adaptable to various grids
- Front access and space efficient. System can be positioned next to wall
- Intelligent battery management function that expands lifetime
- Hot-swap and online maintenance
About the Distribution:
As a golden distributor of Emerson, all of Emerson prodcucts from Polytrade/Sandes Technology are 100 % Original and Brandnew unless per clients’ requests; customers could claim 10time cost if you find we offer used or fake products. We offer one year warranty for all on-display products.
The Emerson products by us are whole series of hot-sell products, and if you did not find what you need on alibaba web, please contact us via sales[at] to gain supports.
Products Photos:
