Cheap Acrylic CNC Router PVC KT Board Engrave/Advertisme
Feature
1 . Original Ncstudio system , easy to learn and convenient to operate
2 . Imported Taiwan Hiwin linear guide rail and Taiwan Hiwin 25 Screw
3 . German Slanting Rear
4 . Big torque stepper motor/Servo motor
Product parameter
Model: |
4STC-1325HD |
Guideway: |
XYZ-axis use liner guideway |
Driving mode : |
XY-axis use rack and Z-axis use Linear Square screw |
XY-axis working area : |
1500*2900mm |
Table Size |
1380*2700mm |
Z-axis working area: |
180 mm |
Feeding height: |
200 mm |
Spindle Speed: |
0-24000mm/min |
Processing speed : |
30000mm/min |
Mechanical precision: |
±0.1mm/300mm |
Compatible Software: |
Type 3 software , Artcut software , Artcam software |
Spindle Power consumption: |
3.0KW with Water Colling Motor(Optional) |
Power source: |
AC220V/50HZ or 380V/50HZ |
Driver type: |
Stepper motor |
Memory: |
Without or DSP |
Spindle: |
3.0KW variable speed , water-cooled motor |
Blade diameter: |
3.175mm, 4mm, 6mm, 12mm or 12.7mm |
Control system: |
NCSTUDIO or DSP(USB interface) |
Command: |
G code , u00, mmg, plt, HPGL |
Running circumstance temperature: |
0-45degree |
Relative humidity: |
30%-75% |
Widely Application
1 .Furniture industry : solid wood furniture , wooden door , cabinet
2 . Wooden products processing : wooden speaker , wooden clock , sports equipent
3 . Musical instrument : 3D surface engraving and shape cutting .
4 . Artware making : photo frame , jewelry box
5 . Electrical industry : circuit board , insulation material , LED disply screen
Suitable Materials
PMMA,PVC Sheet, ABS sheet, KT sheet, Timber ,Gemstone, Marble ,Aluminum and plastic composite panel, Iron, Copper, Aluminum, Plastics and etc.
Products Samples Showing
Technical support
1,Once our business term is down,buyer can send your technical staff to learn related technology of CNC Router in our factory for free.
2,Or we can send our engineer to buyers’ country for technical support,but the buyer should be responsible for the return ticket for them.
Other special requests,pls mention us.
Our Service
1.One year equipment warranty and maintenance for lifetime.
2.Free installation and test before shipping and free training for operators
3.Advice for the solutions best for customers requirements.
4.Free training and sample provided
5.Meet CE,FDA,ISO9001 standards
What can we do?
1),For materials:
Wood(Timber ,Hard wood;plywood;whitewood;red wood,soft wood,MDF and etc) CNC Router Engraving/Carving/Cutting Machine;
Plastic(PMMA,,PVC Sheet,ABS Sheet;KT Sheet;UV,PU,;Aluminum Composite Panel and etc)CNC Router Engraving/Carving/Cutting Machine;
Stone(Tomstone,Gemstone,Granite,Marble and etc)CNC Router Engraving/Cutting/Carving Machine;
Acrylic CNC Router Engraving/Carving/Cutting Machine;
Metal(Iron,Stainless,Aluminum,Copper and etc)CNC Router Engraving/Cutting/Carving Machine;
2)For quantities of Spindle:
Single Spindle CNC Router,2 Spindles CNC Router;3,4...12,15 Spindles and etc Multi-spinldes CNC Router Engraving/Carving/Cutting Machinery;
3)For Axies:
2 Axis CNC Machine,3 Axis CNC Router,4 Axis CNC Engraving Machine,5 Axis CNC Router,6 Axis CNC Router Machine;
4)For Spindle Power:
There are 2.0KW/3.0KW/4.5KW/5.5KW/7.5KW/9.0KW CNC Router Machine;
5)Others,
Plane&Cylinder CNC Router Machine;ATC CNC Router;Automatic Tool Changed CNC Machine;Router Axis CNC Machine;Dual Z Axis CNC Machine;
Heavy-duty CNC Router,Low cost CNC Machine,Enconomic CNC Router;Vac-sorb CNC Engraving Machine;Ncstudio Control System CNC Router Machine;
CNC Laser Machine;CNC Plasma Cutter ;CNC Laser Cutting Machine ,MINI CNC Router and etc.
