widely use cnc router mini automatic engraver 3030 for sale
Industry:
plastic mould, die casting mould, aluminum mould, copper watch, eyeglasses, electric fixture, prototyping, gemstone,ring, decoration, ceramic tile, inkstone, acrylic, PVC, ABS, KT sheet, aluminum plastic sheet, copper, aluminum, plastic, artificial stone, electric wood sheet etc material surface engraving and 3d processing.
Features:
fast speed, high accuracy, good stability, sensible price with high quality, low investment but high effiency.
1.Pictures of widely use cnc router mini automatic engraver 3030 for sale
| Specifications option of the machine | ||||||
| Model No | TC-3030C | |||||
| Platform Size | 350mm(W)*350mm(L) | |||||
| Max working range | 300mm(W)*300mm(L) | |||||
| Z axis traveling height | 130mm | |||||
| Feeding Height | 250mm | |||||
| Structure | Casting iron | |||||
| Table material | Casting iron | |||||
| Thickness of gantry | Casting iron | |||||
| Sheet metal | 2mm baking paint sheet metal | |||||
| Gantry side way | Casting iron | |||||
| Absorption | T-clip(Vacuum, optional) | |||||
| X,Y Axis transmission | Taiwan HIWIN 2510 Auto Anti-gap&doulbe nuts Ball Screw | |||||
| Z Axis transmissior | Taiwan HIWIN 2510 Auto Anti-gap&doulbe nuts Ball Screw | |||||
| Rail configuration | Taiwan HIWIN 20 Linear Square Guide | |||||
| Positioning accuracy | ±0.05/300 mm | |||||
| Spindle power | 1.5KW | |||||
| Spindle Rotating Speed | 0-24000r/min | |||||
| Empty Speed | 0-20000mm/min | |||||
| Processing Speed | 0-20000mm/min | |||||
| Resolution | 0.00625/Pulse | |||||
| Converter | 1.5KW Converter(Sunfar brand) | |||||
| Y Axis Drive motor | Shenzhen Leadshine 86 Stepper motor | |||||
| X,Z Axis Driving | Shenzhen Leadshine 86 Stepper motor | |||||
| Movement Control System | Ncstudio Control System | |||||
| Cooling System | Pump | |||||
| Carving Instruction | G-code, ENG, U00, MMG, NC | |||||
| Stainless Steel Water Tank | 2mm | |||||
| Collet | 3.175mm, 4mm, 6mm | |||||
| Moving Way | Table moving | |||||
| N.W | 150kg | |||||
| Machine Power | 110/220/380V50Hz ±10 (Internal Switch power) | |||||
| Electric Box | Computer Cabinet | |||||
1.Pictures of sample of widely use cnc router mini automatic engraver 3030 for sale
3.Our factory
4.Pictures of our products
We have many kinds of cnc router machines,if you are finding machines
please contact with us,we will try our best to find the most suitable machine
for you.
5. widely use cnc router mini automatic engraver 3030 for sale details with pictures:
Optional parts:
1.The working range can be customized as per your requests;
2.The sturcture: can be Heavy-duty Tubular steel frame Or Lighter steel frame;
3.The table: can be T-slot Aluminum table Or Vacuum table for Maximun Fixturing
Flexibility;
4. Spindle: the power of spindle can be 1.5KW/ 2.2KW/ 3.0KW/ 4.5KW/5.5KW/7.5KW/
9KW, etc;
5. Drive Motor: can be Stepper Motor Or Servo Motor;
6. ATC(Automatic Tool Changing): Can be with Or without, Linear Or Hat shaped;
7. Control system: NcStudio with DSP Or computer cabinet;
8.Water cooling pipe: with Or without;
9. Rotary axis for 3D working: with Or without;
6.Picture of deliver goods
Shipping Terms
1,EXW
2,FOB SZ
3,CIF+Destination port
4,If you need us to book shipping cargo or not and etc,pls notice us,we are more
pleased to do so.
Payment terms
1,T/T 30%T/T in advance against the order confirmed and pay the balance 70%
against goods ready.
2,Western Union Total amount should be below than 5000 USD,and the bank
handling fee should be responsible for you.
3,L/C We would like to talk details with you if you really need L/C payment term
7.Our team
We will focus on your demand,providing you with advise and
information to help you grow !
8.Picture of certificate-CE/FAD/BV and so on
9.Our Service :
1. One year equipment warranty and maintenance for lifetime
2.Free installation and test before shipping and free training for operators
3.Advice for the solutions best for customers requirements
4.Free training and sample provided
