(4STC--1618-6) CNC 3d Glass Engraving Machine With Automic Tools

(4STC--1618-6) CNC 3d Glass Engraving Machine With Automic Tools photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
CNC
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
CNC or Not CNC
Place of Origin Guangdong, China
Brand Name Naik
Model Number 4STC-1325-5
Voltage 220V/ 380V
Dimension(L*W*H) 1380*2900*1500mm
Weight 1100KG
Certification CE ISO9001 FDA SGS
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

                                         CNC 3d Glass Engraving Machine With Automic tools

MODEL   CNC wood machine -4STC-1618-6
NO. Description Parameter
1 X,Y,Z Working Area 1600*1800mm
2 Table Size 1700*2100MM
3 Spindle Power Motor 1.5KW*6PCS optional water cooling
4 Lathe Structure T-Clip
5 X Structure Germany Slanting rack
6 Y Structure Germany Slanting rack
7 Z Structure 25mm dual screw-nut anti-gap rod
8 Max.Speed 0-20000mm/min
9 Max.Working Speed 0-15000mm/min
10 Z-axis travelling height 200mm
11 positioning accuracy ±0.1/300mm
12 Converter Best (6pcs)
13 Spindle Speed 0-24000RPM
14 Working Mode SERVO motor,Stepper motor or options
15 Working Voltage 380Volt / 50HZ
16 Command Code G code(*U00,*nc,*mmg)
17 Control System WeiHong Motion Control System of Shanghai
18 Interface Printer port 50pins or USB
19 system Memory 4GB inner side
20 Diameter of cutting tools (mm) 3.175/ 4.0/ 6.0mm optional
21 X,Y Working Delicacy <0.01mm
22 Software Type3 software original from France
23 Running circumstance Temperature: 0°C~45°C
Relative humidity: 30%~75%
24 Net weight 2000KG
25 Waranty One year
26 Delivery time 1 week after get total payment by T/T transfer
27 upgrade more wider and hard Aluminum table with high quality clamps ,X,Y Axis adopt auto eliminating clearance device, more accuracy ,oil lubrication system standard, ALL AXIS WITH DUST PAPER

Application Materials

Foam, Styrofoam, EPS Foam, Wood, MDF, Solid wood, Hardwood, Artificial stone, Marble, Granite, Ceramic Tile, Tombstone, milestone, Terrazzo, Limestone, Sandstone, Travertine, Quartzite, Slate, grindstone ,Jade, crystal, plexiglass, aluminum composite panel, aluminum block, copper and so on.

(4STC--1618-6) CNC 3d Glass Engraving Machine With Automic tools

Our advantage:



1. Tough precision bearings and hardened steel rails on each axis



2. Reliable rack-and-pinion power transmission on each axis.



3. Positional accuracy of +/- .003



4. Dust Skirt ready to onnect to your dust collector.



5. Free Tech Support and User Forum.



6. One-year warranty.
