Fish Farming Aerator Paddle Wheel Floating Aerator

Fish Farming Aerator Paddle Wheel Floating Aerator photo-1
Fish Farming Aerator Paddle Wheel Floating Aerator photo-2
Fish Farming Aerator Paddle Wheel Floating Aerator photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
JW
Model Number:
JW518
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or customer need
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Henan, China
Brand Name JW
Model Number JW518

Paddle wheel aerator /fish pond aerator fish pond aerator fish farming aerator paddle wheel floating aerator

Introduction:

We can supply you 2-wheel and 4-wheel,6-wheel,structure aerator for fishpond. It matches with

1hp&2hp motor and high-quality reducer so that the paddle wheel could be more stable

and not easy to swing during operation.

Characteristics:

1.Arcuate-bevel gears are used instead of worm gears, thereby economizing on energy with high efficiency,and saving over 20% electric energy over traditional models.

2. The arcuate-bevel gear is made of chromium-manganese-titanium with carbon-nitride surface treatment. Ensuring long usage life spans and high rigidty.

3. Mechanical seal is available to prevent oil leakage

4. Inside protectors are avaible to avoid the motor being accidentally burnt out.

5..High effciency oxygen transferring ability with 3.5kgs O2/h

6.Have good water current circulation as the making of large aera water wave






Parameter:

Model

Power

Aerobic capacity

Power Efficiency

Rotating Speed

Impeller No.

Overall Size

Weight

TZYL

-0.75

0.75 kw

≥1.1 (kg/h )

1.25 kg/kw.h

1400 r/min

 2 pcs

1500*1580*850 mm

80kg

TZYL

- 1.5

1.5 kw

1.9 (kg/h )

1.25 kg/kw.h

1400 r/min

4 pcs

2000*1580*850mm

100kg

TZYL

-2.2

2.2kw

2.8 (kg/h )

1.25 kg/kw.h

1400r/min

6 pcs

2500*1580*850 mm

120kg



Main Parts:

No.

Item Name

Quantity

Referance

Function

1

Motor

1 set

0.75KW, 3phase/single phase, 4p/2p, cast iron body,

Provide power

2

Reducer

1 set

Gear style, 14:1/16:1 Cast Iron body

Transferring the power speed

3

Floats

3 pcs

100% new material HDPE

Support the main machine

4

Impellers

4 pcs

100% new material PP

Paddle the water

5

Transmission shaft

2 pcs

304# Stainless steel

Transferring the force

6

Frame

1 pcs

304# angle stainless steel

Supporting and fixing the machine





 No2:                                        No4:                                     No6:

fish farming aerator paddle wheel floating aeratorfish farming aerator paddle wheel floating aeratorfish farming aerator paddle wheel floating aerator

Parts:

fish farming aerator paddle wheel floating aeratorfish farming aerator paddle wheel floating aeratorfish farming aerator paddle wheel floating aerator

fish farming aerator paddle wheel floating aerator

Packaging & Shipping

 fish farming aerator paddle wheel floating aerator





FAQ

 fish farming aerator paddle wheel floating aerator
