3meluck Refrigeration Suction Line Accumulator for cold room Refrigeration System compressor

PRODUCTS INTRODUCTION:

This Accumulator is designed with bend pipe to prevent internal splashing and contributing to the oil collection at the bottom of the separator, and the bend pipe should be installed near the compressor as possible.

FEATURES:

1. "U" shape pipe designed keeps maximum refrigerant flow capacity and the least oil blocking.

2. Entrance of type "U" siphon is in the back of inlet oriented pipe preventing liquid entering into compressor and destroying it.

3. Throttle hole is matching well with system capability to ensure the best about the liquid refrigerat that flow into compressor.

4. Surface corrosion resistant static electrical painting procedure protecting the shell from the rust.

5. Maximum working pressure: 3.0 Mpa.

DESIGN FUNCTION:

1. ODF connection (TP2Y2);

2. End cover (St12);

3. Oriented pipe (Q235);

4. "U"  angle pipe (Q235);

5. Steel shell (Q235);

6. Throttle hole.
