Home > Manufacturing & Processing Machinery > Machine Tools > Drilling Machine > Z3080HX20 Radial Drilling Machine

Z3080HX20 Radial Drilling Machine

Name: Z3080HX20 Radial Drilling Machine
Brand: YuanHang
SKU: 119155277
Availability: InStock

Z3080HX20 Radial Drilling Machine thumbnail-1

Z3080HX20 Radial Drilling Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

Normal

Place of Origin:

Shaanxi, China

Contact Supplier Request Quote Chat Now

Shaanxi Yuan Hang Machinery Equipment Import & Export Corp., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not Normal

Place of Origin Shaanxi, China

Brand Name YuanHang

Model Number Z3080HX20

Specifications

1.CE,standard
2.No.1 quality in the market
3.High quality to price ratio
4.spare parts support

Z3080H×20 Radial Drilling Machine is suitable for drilling, counter-boring, reaming, spot-facing and tapping on large and medium size object.

Max. diameter to drill(cast iron)	80 mm
Distance from the spindle Axis to the column surface	Maxi. 2000 mm/Min. 500 mm
Max. travel of headstock	1500 mm
Distance from the spindle end face to Worktable surface	Max. 2000 mm/Min. 550 mm
Taper hole in spindle	Morse NO.6
lifting speed of arm	1.00 m/min
Max. travel of arm on column	1000 mm
Max. travel of spindle	450 mm
Spindle travel per circle of dial	151 mm
Spindle speed range	16-1250 r/min
Spindle speed numbers	16
Spindle feeding range	0.04-3.2 mm/r
Spindle feeding numbers	16
Max. torque of spindle	1568 N.M
Max. feeding resistance	34300 N
Main motor power	7.5 kw
Arm lifting motor power	3 kw
Hydraulic pressure clamp motor	0.75 kw
Cooling pump motor	0.125 kw
Net Weight (approx)	10.5 ton
Overall dimensions	3230×1400×3795 mm

Accessories: Morse taper reduction sleeves, Drift, Reducing sleeves
Note: The descriptions and specifications given in the pamphlet are subject to our alteration and without notice.
