Z3063*20A RADIAL DRILLING MACHINE
- 0 per Month
- Shanghai
- T/T
Product Details
Condition: | New | CNC or Not: | Normal | Place of Origin: | Shaanxi, China |
Brand Name: | Yuanhang | Model Number: | Z3063*20A |
Product Description
Specifications
1.CE,standard2.No.1 quality in the market
3.High quality to price ratio
4.spare parts support
Characters
Gather mechanical-electrical-hydraulic functions, use extensively.
With wide range of speed and feed, with manualpower and fine feeds. The feed
of machines are very easily engaged and disengaged at any time.
With safe and reliable feed safety machine, all parts easy operation and change.
All controls centralized on the head stock easy operation and change. Clamping
for assemblies and speed change of spindle achieved by hydraulic power, cmle
is sensing owlet Nellie.
Main parts are made by machine center which import form KIA with high precision
and efficiency, ensuring reliability and high quality.
Integrating technology for casting parts is excellent, adopting casting equipment,
ensuring high quality of material for basic parts.
Spindle parts are made by special high quality steel heat treatment to be made by
first class equipments, Suring high strength and durability.
Main gears are machined by gear grinding, the machine ensuring high precision
and low noise.
Standard accessories
Box shape worktable
Taper sleeve
Tool releasing Wrench
Drift
Eyelet bolts
Special accessories
Quick instead Chuck
Tapping chuck
Grease gun
Parameters
Model | Z3063×20A |
Max. Drilling capacity | 63 |
Distance spindle axis to column generating line (mm) | 450-2050 |
Diameter of column (mm) | 450 |
Spindle taper | MT5 |
Spindle travel (mm) | 400 |
Spindle speeds range (r/min) | 20-1600 |
Spindle speeds series | 16 |
Range of Spindle feeds (r/min) | 0.04-3.2 |
Spindle feeds | 16 |
Max. Distance spindle nose to working surface of base (mm) | 400-1600 |
Dimension of worktable (mm) | 960×630×500 |
Dimension of base (mm) | 2900×1250×250 |
Overall Size (mm) | 3110×1250×3150 |
Power of Main motor (KW) | 5.5 |
G.W/N.W (kg) | 8000/7000 |
Packing dimension (cm) | 347×147×235 |
Contact Us
- Shaanxi Yuan Hang Machinery Equipment Import & Export Corp., Ltd.
- Contact nameZHENG QI CHEN
- Phone86-29-87801605
- AddressNo. 69, Xingfu Middle Road, Xincheng Dist.
-
