Home > Products > Mixer series > Model SBH Series 3D Swinging Mixer
Model SBH Series 3D Swinging Mixer
- 30 Set / Sets per Month
- shanghai china
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Mixer Type: | Planetary Mixer | Product Type: | Detergent Powder |
Application: | Viscous Fluid | Additional Capabilities: | Drying | Place of Origin: | Jiangsu, China |
Brand Name: | xinanfenti | Model Number: | SBH | Max. Loading Capacity: | 800L |
Voltage: | 100-300 v (According you requirement) | Power(W): | 7500W | Dimension(L*W*H): | 2250*2600*2600 |
Certification: | ISO9001,Accord with GMP standards | Warranty: | 1 years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Model SBH Series 3D Swinging MixerISO9001,Accord with GMP standards
The machine is applied in the industries of pharmaceutics
Model SBH Series 3D Swinging Mixer
Main Application:
Model SBH Series 3D Swinging Mixer
is made of stainless steel and applied in pharmaceutical,chemical,foodstuff industry for mixing dry powder.Materials in different granule size and different proportion can be mixed rapidly.
Operating Principle:
The machine is powered by an alternating pulse and continuously mixes in 3D motion-horizontal moving,up-down swing and rotation.It has a good performance on low noise,stability and reliability in operation,high load and shorter mixing time.
Model | Volume Barrel(L) | Loading capacity(L) | Barrel largest installed(kg) |
SBH-50 | 50 | 40 | 40 |
SBH-100 | 100 | 75 | 75 |
SBH-200 | 200 | 160 | 160 |
SBH-300 | 300 | 340 | 340 |
SBH-400 | 400 | 320 | 320 |
SBH-500 | 500 | 420 | 420 |
SBH-600 | 600 | 480 | 480 |
SBH-800 | 800 | 640 | 640 |
SBH-1000 | 1000 | 800 | 800 |
Speed(rpm) | General Motors Power(kw) | Overall size(L×W×H) | Weight(kg) |
0-15 | 1.1 | 1000×1400×1200 | 300 |
0-15 | 1.5 | 1200×1700×1500 | 500 |
0-15 | 2.2 | 1400×1800×1600 | 800 |
0-15 | 4 | 1800×1950×1950 | 1200 |
0-15 | 4 | 1800×2100×1950 | 1200 |
0-15 | 5.5 | 1900×2100×2100 | 1380 |
0-15 | 5.5 | 1900×2100×2250 | 1500 |
0-15 | 7.5 | 2200×2400×2300 | 2000 |
0-15 | 7.5 | 2250×2600×2600 | 2500 |
