EDM Electrode Tube / EDM Brass Tube For EDM Dilling Machine 0.3mm x 400mm
1.Size:0.3mm *400mmL
2. Material:Copper &Brass
3.Packing: 100 pcs in a plactic tube
4.Fitting for all edm drilling machines
Immediately delivery after payment for large quantity in store available.
Brass / Copper single hole edm electrode tube list
| OD (mm) | Length(mm) | Packing (pcs) |
| 0.1 | 150mm / 200mm | 50 |
| 0.13 | 150mm / 200mm | 50 |
| 0.15 | 150mm / 200mm | 50 |
0.2 |
150mm / 200mm | 50 |
0.3 |
400mm | 100 |
| 0.4 | 400mm | 100 |
| 0.5 | 400mm / 500mm / 700mm | 100 |
| 0.6 | 400mm / 500mm / 700mm | 100 |
| 0.7 | 400mm / 500mm / 700mm | 100 |
| 0.8 | 400mm / 500mm / 700mm | 100 |
| 0.9 | 400mm | 100 |
| 1.0 | 400mm | 100 |
| 1.1 | 400mm | 100 |
| 1.2 | 400mm | 100 |
| 1.3 | 400mm | 100 |
| 1.4 | 400mm | 100 |
| 1.5 | 400mm | 100 |
| 1.6 | 400mm | 90 |
| 1.7 | 400mm | 80 |
| 1.8 | 400mm | 70 |
| 1.9 | 400mm | 60 |
| 2.0 | 400mm | 50 |
| 2.1 | 400mm | 50 |
| 2.2 | 400mm | 40 |
| 2.3 | 400mm | 40 |
| 2.4 | 400mm | 35 |
| 2.5 | 400mm | 30 |
| 2.6 | 400mm | 30 |
| 2.7 | 400mm | 25 |
| 2.8 | 400mm | 25 |
| 2.9 | 400mm | 25 |
| 3.0 | 400mm | 20 |
Feature
1. Provide single channel & multi channel types brass and copper tubes to cope with different use.
2. High accuracy, the smoothness of the hole surface can be maintained.
3. The tube body is absolutely straight, ensuring that the process is keeping high accuracy when it is under discharging.
Our business range
. EDM brass wire
. EDM filter
.EDM resin
.EDM Rust Remover
.EDM Consumables
wire guide,power feed contact,rollers,water nozzle,belt,discharge cable,etc.
.EDM drilling tool
Full range EDM accessories solution!
Company profile
We are EDM consumable parts manufacturer that employs innovative technology to manufacture EDM water filter, wires and other nonrepairables such as wire guide, power feed contact, pinch roller etc. Our product ranges are widely used in Charmilles, Mitsubishi, Sodick, Fanuc, Makino, Chmer, Seibu, Brother etc. Molding design, tooling manufacturing and high accuracy machining technology are applied to provide our customers with complementary precision motion control elements. And we walk with you during each step from forming your needs to meeting your needs...
We offer across-the-aboard introduction, material selection and trail order test for approval to meet your unmatched need and to reduce cost. We draw on our experience in the manufacture uncounted filters and brass wires plus repeatability and consistent quality are ensured throughout each production run. The results are quantifiable. Our record is clear.
As a big EDM supplier & wholesales that offers a full inventory of mold accessories.We offer our sustomers the opportunity to cut purchasing costs by providing needed key products from a single vendor.We are continually develop new ,high quality products to meet the conditions of clients need.
We would like to thank our customers for the continued support . We are going ot offer better service for the years to come.
