Retract Button Bit
US$ 5 - 300
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
MIROC
Model Number:
R32,R38,T45,T51,ST58,ST68
Payment & Shipping
Payment Methods:
Port of Shipment:
Tian Jin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RL-3 Underground Load Haul Dump MachineUS$ 80,000 - 130,000MOQ: 1 Set -
Dump TruckUS$ 80,000 - 200,000MOQ: 1 Set
-
China High Quality Self Drilling Rock Anchor Bolt,R32N, Alloy Structure SteelUS$ 1.8 - 21MOQ: 50 Meters
-
Underground Mining Threaded Drill Coupling for Rock Drilling ToolUS$ 10 - 300MOQ: 5 Pieces
-
China High Quality Self Drilling Rock Anchor Bolt,R32N, Alloy Structure SteelUS$ 1.8 - 21MOQ: 50 Meters
Place of Origin
China
Brand Name
MIROC
Model Number
R32,R38,T45,T51,ST58,ST68
Type
Drill Bit
Machine Type
Drilling Tool
Certification
API
Material
Carbide
Processing Type
Forging
Use
Ore Mining
Spherical Button Characteristics:
1. Universal button
2. Good wear resistance
3. Best suited for hard ground
4. 27000-48000PSI(180 to 320Mpa)
5. Suited for abrasive to very abrasive drilling conditions
Ballistic Button Characteristics:
1. Fast Penetration
2. Best suited for soft rock
3. 10000-20000PSI(70 to 140Mpa)
4. Suited for non-abrasive drilling conditions
Techanical parameter
| T51 button bit | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 89 | 3x11, 2x11 | 6x13 | 4 | - | 4.9 |
| 2 | 102 | 3x13, 2x13 | 6x14 | 3 | 1 | 5.2 |
| 3 | 115 | 6x14 | 8x14 | 2 | - | 6.8 |
| 4 | 127 | 4x16, 2x13 | 8x16 | 4 | - | 7.5 |
| T45 button bit | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 70 | 3×11, 1×19 | 6×11 | 3 | - | 2.2 |
| 2 | 76 | 3×11, 1×11 | 6×13 | 3 | - | 2.4 |
| 3 | 89 | 3×11, 2×11 | 6×13 | 3 | 1 | 4.1 |
| 4 | 102 | 3×13, 2×13 | 6×14 | 3 | 1 | 4.5 |
| T38 button bit | ||||||
| Bit Dia. | Buttons and Size (mm) | Flushing Hole | Weight | |||
| mm | Front | Gauge | Front | Side | kg | |
| 1 | 64 | 3×10, 1×10 | 6×11 | 3 | - | 1.8 |
| 2 | 70 | 3×10, 1×10 | 6×12 | 3 | - | 2.6 |
| 3 | 76 | 3×11, 1×11 | 6×12 | 3 | 1 | 2.6 |
| 4 | 89 | 3×11, 2×11 | 6×13 | 3 | 1 | 3.3 |
Packaging & Shipping
Carton box and wooden box
What will you get here?
1. Competitive factory price
2 .Hight quality
3. Delivery on time
4.Excellent after-service
