3m³ / 6000kg Rl-3 Load Haul Dump Machine With Deutz Air Cooled Diesel Engine
The RL-3 Load-Haul-Dump Machine is ideal for medium to large scale rock excavation operations.The RL-3 maintains the simple yet very robust design tenets of what a mining equipment should be - it has high proven reliability, and straight-forward mechanical components that are easy to maintain.
Applications
• Underground Mining
• Hydropower Tunneling
• Roadway/Railway Tunneling
• Can be utilized as a multi-role equipment with various attachments (i.e. shotcrete robot arm)
Competitive Advantage
• Major components from industry respected suppliers
• Simple yet very robust design
• Very competitive pricing compared to its counterparts coming from well-known brands
• Competitive delivery
Specification
| RL-3 Load-Haul-Dump Machine Main Dimensions | |
| Length | 8868mm (Haul postion) |
| Width | 2112mm |
| Height | 2275mm |
| Turning Radius | 3600mm(Inside) |
| 6400mm(Outside) | |
| Volume Capacity | 3m³ |
| Tramming Capacity | 6000kg |
| Engine | DEUTZ BF6L914C Turbocharged with charge aircooler, air cooled diesel engine |
| Torque Converter | DANA C273 |
| Transmission | DANA R32000 |
| Axles | DANA 16D |
| Tires | 17.50-25.00 L5-S |
Tags: Load Haul Dump Machine, Low Profile Dump Truck
KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations.
ROXMECH®, by KSQ Technologies (Beijing) Co. Ltd., is a product line consisting of specialized equipment for use in underground mining and tunneling works, such as Load-Haul-Dump Machines (LHDs), Low Profile Trucks (LPTs), Scissors Lift Truck, Mobile Batching Equipment, Service Vehicles, and Personnel Carriers.
ROXMECH® was developed through years of exchanges and hands-on work with mining operations in China and some parts of the world where mining is the lifeblood of the economy. In every product we build, our reputation and experience can be seen. That’s the reason to choose us if you are looking to improve your productivity and reduce costs.
ROXMECH® Rock Excavation and Service/Support Equipment include:
RL-1 Load-Haul-Dump Machine
RL-2 Load-Haul-Dump Machine
RL-3 Load-Haul Dump Machine
RL-4 Load-Haul Dump Machine
RT-12 Low Profile Dump Truck
RT-15 Low Profile Dump Truck
RT-20 Low Profile Dump Truck
MT30D Low Profile Dump Truck
Contact us for more information on our products and services.
