China Hot Sale 3.2m Sweeping width Cleaning Truck
- 224 Piece / Pieces per Month
- Qingdao Port Tianjin port Lianyungang port Shanghai port
- T/T D/P D/A Credit Card PayPal
- FAW 4x2 6 wheel 16cbm machanical road sweeper trucks
- Shacman X9 4x2 road cleaning truck sweeper
- Sinotruk howo road sweeper truck 10cbm 12cbm
- Isuzu 700P diesel engine sweeper truck japan road sweeper truck
- Foton 4x2 mini 6 wheel broom sweepers truck 2800 liters
- Dongfeng KINLAND 6x4 6x6 price of road sweeper truck
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | YUTONG |
Model Number: | YTZ5050TSL70E | Dimension(L*W*H): | 5650x2000x2350 | Weight: | 4420 |
Certification: | ISO | Warranty: | 12months/2000hours | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
China Hot Sale 3.2m Sweeping width Cleaning Truck
Main Technical Parameters
Item | Parameter |
| |
1. Dimension parameters | |||
Overall dimension (L × W × H) | 5650×2000×2350mm | ||
Front suspension | 1015 mm | ||
Rear suspension | 1275 mm | ||
Angle of approach | 24° | ||
Angle of departure | 25° |
| |
Minimum ground clearance | 190 mm | ||
Volume of garbage compartment | 5 m3 | ||
Volume of water tank | 1100 L | ||
2. Mass parameters | |||
Kerb mass (kg) | 4420kg | ||
Mass of front axle (no load) | 1800kg |
| |
Mass of rear axle (no load) | 2620kg | ||
Mass of front axle (full load) | 1920kg | ||
Mass of rear axle (full load) | 3380kg | ||
Max. gross mass | 5300 kg (Including two people) | ||
3. Performance Parameters | |||
Sweeping width | 2.5-3.2m |
| |
Operating speed | 3-15km/h | ||
Maximum vehicle speed | 98 km/h | ||
Tipping angle for garbage | 60° | ||
Maximum cleaning efficiency | 96% | ||
Operating fuel-consumption (8Km/h) | 6.8L/h | ||
Driving fuel-consumption | 10.6L/100km |
| |
Chassis model | QL10508HARY (Qingling Brand) | ||
Maximum power | 70kW /3400 rpm | ||
Max. torque | 206N.m/1700rpm | ||
Model of auxiliary engine | JE493G3-201 | ||
Maximum power | 57kW /3600 rpm |
1.The truck adopts a technological structure: four sweeping brushes are mounted on left and right sides and a wide suction nozzle is mounted in the middle. 2. Sweeping brushes of the street sweeping truck are equipped with automatic avoidance device. The street sweeper truck is featured by centralized operating devices, constant space between suction nozzle and ground, etc. 3. Both of water tank and dustbin are made of 304 stainless steel materials. The water tank, with double stainless steel structure, is firm and durable and has strong corrosion resistance! 4. A low water level sensing alarm system is equipped within the water tank. It will automatically give an alarm when there is no water in the tank, so as to prevent the water pump from being damaged due to water shortage . 5. The street sweeping truck selects and uses "imported hydraulic block". The hydraulic system is further optimized. 6.As for the heat dissipation of hydraulic oil, water cooling system is equipped, which can fully guarantee the normal operation of the truck in the hot summer . | |
7.The street sweeping truck uses Qingling chassis; the cab is equipped with air conditioner; turbocharged and inter-cooled engine; low fuel consumption, powerful power, good handling, comfortable and luxurious; the cab is wide and bright and has wide field of view! 8. Centralized electrical control box of the street sweeping truck is used to control the truck and it can be controlled by one key in the cab, with high level of automation. 9.A voice alarm device is equipped to accurately broad cast a variety of safety tips and failures; meanwhile, through working camera, optional GPS satellite positioning, reversing radar and other devices, operator can conduct real-time monitoring on the truck |
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
