Drill rod using T38, T45, T51 thread system. In good rock conditions it will produce straighter holes and at least 10% higher penetration rate compared to rod and coupling sleeve combination system. Used in benching and long hole drilling.
T38 T45 T51 extension Rod
Product Basic Information:
Product Name: |
Extension Rod |
Thread |
T38,T45,T51 |
Diameter |
39mm-52mm |
Length |
1220-6095mm |
Material: |
High strength alloy steel |
Type |
Round and Hex |
Color |
Black or based on customer requirements. |
MOQ: |
No MOQ required for testing and trial order |
T38 extension rod Specification:
| THREADED ROCK DRILLING TOOLS - T38 Extension Rod | |||||||
| Drill rod | Length | Diameter | Weight | Part Number | |||
| mm | foot | mm | inch | kg | |||
| Extension rod, T38-Round39-T38 | 1220 | 4 | 39 | 1 1/2 | 10.2 | 4148300772 | |
| Flushing hole 14.5mm | 1525 | 5 | 39 | 1 1/2 | 12.8 | 4148300773 | |
| Wrench flat 32mm | 1830 | 6 | 39 | 1 1/2 | 15.3 | 4148300774 | |
|
|
2435 | 8 | 39 | 1 1/2 | 20.4 | 4148300775 | |
| 3050 | 10 | 39 | 1 1/2 | 25.5 | 4148300776 | ||
| 3660 | 12 | 39 | 1 1/2 | 30.9 | 4148300777 | ||
| 3965 | 13 | 39 | 1 1/2 | 33.2 | 4148300778 | ||
| 4270 | 14 | 39 | 1 1/2 | 35.7 | 4148300779 | ||
| 4880 | 16 | 39 | 1 1/2 | 41.0 | 4148300780 | ||
| 5530 | 18 1/7 | 39 | 1 1/2 | 46.3 | 4148300781 | ||
| 6095 | 20 | 39 | 1 1/2 | 50.9 | 4148300782 | ||
HS Code: 82071990
Product Pictures:
Applications:
• Underground mining
• Tunneling,quarrying
• Widely used in benching, and long hole drilling
Production Process:
1. Raw material 2. CNC milling and proprietary heat treatment process 3. Inspection 4. Package.
Competitive Advantage:
High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance.
The information you may like to know before order:
1. Methods of Payment:
T/T (Telegraphic Transfer) or L/C at sight
2. Handling time for an order
Based on order quantity, normally it takes 25 days for production.
Only 2 or 3 days if we have stock on your request size.
3. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
4. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
5. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available at any time
c. Free replacement will be provided once the failure confirmed caused by our product quality
Packaging & Shipping
1. 20pcs/ wooden box
2. Shipping by sea
3. Package pictures
Fair&Clients visit:
KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:
- Hazardous environment
- Acts, regulations, and other government guidelines that has to be followed
- Significant differences in the way people work, mostly due to physical constraints
- Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
KSQ Technologies (Beijing) Co. Ltd. has significant experience and know-how in the supply of materials, components, finished goods, specially designed/engineered equipment, and services from China. The company caters to medium to large scale clients who are doing projects and capital expansion, as well as to firms who require support with consumable products, maintenance, and repair operations.
Please feel free to contact us at any time, we will be always here for supporting you!
Skype: alice. zhang1106
Whatsapp:+86-18201011129
