T38 Speed Drill Rod CNC Tool

T38 Speed Drill Rod CNC Tool thumbnail-1
T38 Speed Drill Rod CNC Tool photo-1
Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
GR32-T38-1830 to GR32-T38-6095
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing or Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number GR32-T38-1830 to GR32-T38-6095
Type Other, T38 Guide Speed Rod
Material Tungsten Carbide
Use PCB Drilling

Specifications

High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance



Product Description



Detailed Product Description






Round Alloy Steel Rock Drill Rod T38 Guide Speed Rod Flushing Hole 17mm



Description

Drill rod using T38 thread system. Drilling precision can be further improved by using this as the first rod in a normal drill string. Furthermore, since this is a speed rod design it will produce straighter holes and at least 10% higher penetration rate in good rock conditions compared to rod and coupling sleeve combination system.

• R28 thread system
• Suitable for small hole range


Color: Based on Customer requirements


Material: Tungsten carbide and high strength alloy steel


Processing: CNC milling and proprietary heat treatment process


Type: T38 Guide Speed Rod T38-Round 46-T38 Flushing Hole 17 mm



Applications


• Underground Mining
• Tunneling



Competitive Advantage


High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance



specification

<

Part Number Product Code and Brief Description

Length

(mm)

Length

(ft/inch)

Diameter

(mm)

Diameter

(inch)

Weight

(kg)
4148300796

GR32-T38-1830,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

 1830 6     46 1 4/5 23.5
4148300797

GR32-T38-3050,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

 3050 10     46 1 4/5 37.2
4148300798

GR32-T38-3660,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm


 3660 12     46 1 4/5 44.0
4148300799

GR32-T38-4270,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

 4270 14     46 1 4/5 50.9
4148300800

GR32-T38-4880,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

 4880 16     46 1 4/5 57.7
4148300801

GR32-T38-5530,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

 5530 18 1/7 46 1 4/5 65.0
4148300802

GR32-T38-6095,

T38 Guide Speed Rod,

T38-Round 46-T38,

Flushing Hole 17 mm

 6095 20     46 1 4/5 71.3
