120hp Engine Used Price Road Roller Compactor
MODEL |
YT214B |
|
|
Operating mass |
Kg |
14000 |
|
Static linear load |
N/cm |
326 |
|
Vibrating amplitude |
Mm |
1.7/0.8 |
|
Vibrating frequency |
Hz |
30 |
|
Centrifugal force |
KN |
290/160 |
|
Travel speed |
|
||
1st gear |
2 |
||
2nd gear |
4 |
||
3rd gear |
10.5 |
||
Grade ability |
% |
30 |
|
Turning radius |
mm |
7000 |
|
Overall dimension |
mm |
5900X2280X3050 |
|
Ground clearance |
mm |
432 |
|
Diesel model |
YC6B120 |
||
Diesel power |
K w |
88 |
|
Tire Size |
23.1-26 |
||
Vibration round width |
mm |
2100 |
|
Wheelbase |
mm |
3185 |
|
Diesel engine |
|
Manufacturer: Yuchai Model: YC6B120 |
|
Tire |
|
Manufacturer: Qianjing/Fengshen/Chaoyang |
|
|
Special drive axle for self-made road roller |
||
Drive axle |
|
Special gearbox for self-made land roller |
|
Vibration system |
|
Joint venture brand Tianjin PERMCO gear pump and motor |
|
Optional diesel engine |
|
Optional Cummins 6BT5.9 engine, 110KW SHANGCHAI SC5D130 engine. |
|
Non-detachable |
|
Optional |
|
Detachable convex block wheel |
|
Optional |
|
Air conditioner |
|
Optional |
|
Compactness tester |
|
Optional |
|
Tire |
|
None |
|
Mechanical heavy duty single drum vibratory rollers effect powerful centrifuga force and great static linear load, are suitable for non-cohesive materials, such as sandy soil,gravel,crushed stones, rock fillings and slightly cohesive soils, designed for large foundation constructions such as high-class highways, mines, dams, airports, harbors, railways and industrial areas etc. 1.Mechanical travel drive, double amplitude, hydraulic vibration and steering with optimal function/price ratio and reliable performance. 2.Reliable YUCHAI diesel engine for convenient operation and maintenance. 3.Two sets of brake devices, a hand brake and foot pedal brake, assure the machine's safety and dependability. 4.Spacious and comfortable cab mounted on top quality rubber damping elements. 5.World advanced technology is adopted for the hydraulic vibration technology, high in reliability, simple and convenient in maintenance, and low in cost. 6.Equipped with padfoot or removal padfoot as option. |
|
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
|
|
|
|
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
|
