Help CenterCharger Diode S1M
Related Products
-
Power Supply Diode S1MUS$ 0.001 - 0.01MOQ: 1 Box -
(ic) SR28 SR280US$ 0.001 - 0.01MOQ: 1 Box
-
Power Diode Rectifier Diode 1N4007 IN4007US$ 0.004 - 0.01MOQ: 1 Box
-
Power Supply Diode IN4007 In4007s 1n4007 1n4007sUS$ 0.004 - 0.01MOQ: 1 Box
-
Diode IN4007 In4007s 1N4007 1N4007SUS$ 0.004 - 0.01MOQ: 1 Box
Silicon Rectifier Diode Fast Recovery Rectifier Diode High Efficiency Rectifier Diode
Ultra Fast Rectifier Diode Super Fast Rectifier Diode Schottky Rectifier Diode
Bridge Rectifier Switching Diode Zener Diode TVS Diode DIAC
Features
The plastic package carries Underwriters Laboratory Flammability Classification 94V-0
Ultra fast switching for high efficiency
Low reverse leakage
High forward surge current capability
High temperature soldering guaranteed: 260 C/10 seconds,0.375”(9.5mm) lead length, 5 lbs. (2.3kg) tension
Electrical Characteristics
| TYPE | Maximum Peak Reverse Voltage | Maximum Average Rectified Current | Maximum Peak Forward Surge Current | Maximum Forward Voltage | Maximum Reverse Current | Case Style | |
| VRRM | IAV | IFSM | VF@IF | IR@TA=25℃ | |||
| V | A | A | V | A | μA | ||
| S1A | 50 | 1 | 30 | 1.1 | 1 | 5 | SMB |
| S1B | 100 | 1 | 30 | 1.1 | 1 | 5 | SMB |
| S1D | 200 | 1 | 30 | 1.1 | 1 | 5 | SMB |
| S1G | 400 | 1 | 30 | 1.1 | 1 | 5 | SMB |
| S1J | 600 | 1 | 30 | 1.1 | 1 | 5 | SMB |
| S1K | 800 | 1 | 30 | 1.1 | 1 | 5 | SMB |
| S1M | 1000 | 1 | 30 | 1.1 | 1 | 5 | SMB |
Tape&Box Packing Detail
| Package | QTY Per Box (pcs) | Reel DIA | Carton Size (mm) | QTY Per Carton | Gross Weight (kg) |
| SMB | 3000 | 330 | 365*365*360 | 48000 | 16 |
Water Proof & Moisture Proof Packing
Shipping Service
1. We will ship your order within 7-15 working days after the order confirmation.
2. We can ship via your TNT/DHL/UPS/Fedex account.
3. FOB/CIF/CNF.
1. Free Sample.
2. CY/ MIC/ OEM.
3. Payment Terms: 100% TT before shipment basing on FOB terms.
30% TT advanced payment, 70% TT against BL copy on CNF terms.
4. We can lower invoice goods value to reduce your import tax for the customs.
5. Test report provided for each shipping.
Changzhou Trustec Co., Ltd
Changzhou Changyuan Electronics Co.,Ltd
Professional and leading diode manufacturer in China with ROHS and ISO9001:2008 certification.
Products: silicon diode, switching diode, high efficiency diode, trigger diode, schottky diode,
SMD diode, energy saving lamp diode and switching power supply diode.
Production capacity: 300KKpcs diodes per month.
Top quality: OEM for Good-ark electronic, Star Sea electronic and cooperate with Pentium electrical, NVC, TCL, Honeywell Lonon etc.
Q1: Do you have a test room?
Yes, we have professional staff to take various detection and life test for every batch of diodes,
and special simulation testing equipment aimed at the lighting industry.
Q2: What is your Lead Time?
1.For general diode and standard printing and packaging request, shipment in 3 days.
2.For special printing or packaging the first time, normal lead time would be 15 days.
3.If the order quantity is large, we hope customers place order 15 days in advance.
Q3: Can customers provide logo by themselves?
We can print according to the samples provided by customers if they need special requirement,
but delivery time would be longer because of the extra producing time for printing mold and packaging material.
Q4: Why choose cooperation with CY?
1.Monthly production capacity up to 300 million pieces and short delivery time.
2.Factory and products pass ISO9001:2008 certification, all products are conformed to RoHS.
3.Export team with 8 years of professional export experience can meet various customer requirements.
4.OEM for Good-ark electronic, Star Sea electronic and cooperate with list companies NVC, TCL etc.
