Carbide Tapered Rope Threaded Button Bits

Carbide Tapered Rope Threaded Button Bits thumbnail-1
Carbide Tapered Rope Threaded Button Bits photo-1
US$ 5 - 98 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
Rope Thread Bits
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number Rope Thread Bits
Type Other, Drill Bit, Rope Thread Bits
Material Other, Tungsten Carbide, Tungsten carbide
Use Other, Metal Drilling, Well drilling,mining drilling,ore drilling



Product Description

 Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered button bits for faster drilling penetration rate. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.



• Suitable for small hole rang

• Widely used in Dimensional Stone Quarrying Industry

• Widely used in Underground Mining Industry

Tapered drilling tools Types

Diameter          (mm)

Taper Angle (Degree)

Skirt

Weight (kg)

Tapered chisel bits

20-60mm

4°,6°,7°,11°,12°

Normal, Length

0.15 - 0.45

Tapered cross bits

32-60mm

Normal, Length

0.18 - 0.7

Tapered button bits

30-55mm

Normal, Length

0.2 - 0.5

Carbide Tapered Rope Threaded Button Bits

Carbide Tapered Rope Threaded Button Bits

Carbide Tapered Rope Threaded Button Bits

Button bit and Insert types

Spherical Button Characteristics:
1.Universal button
2.Good wear resistance
3.Best suited for hard ground
4.27000-48000PSI(180 to 320Mpa)
5.Suited for abrasive to very abrasive drilling conditions


Ballistic Button Characteristics:
1.Fast Penetration
2.Best suited for soft rock
3.10000-20000PSI(70 to 140Mpa)
4.Suited for non-abrasive drilling conditions

Carbide Tapered Rope Threaded Button Bits

Applications

• Underground mining

• Dimensional Stone Industry
• Tunneling,quarrying



 Feature

1.tapered button bits connect with tapered drill rod for drilling holes

2.Stale and mature welding technology ensure good quality of bits

3.Accurate dimension of taper degree perfectly matches the rods

reliable and very cost-effective



Specification of tapered button bits

Part Number Bit Diameter (mm) Bit Diameter (inch) Front Buttons (No. x mm) Gauge Buttons (No. x mm) Angle Front Flushing Holes Side Flushing Holes Weight (kg)
4148300271 41 1 3/5 2x7 5x9 35° 1 1 0.41
4148300272 32 1 1/4 2x7 5x7 35° 1 1 0.3
4148300273 33 1 2/7 2x7 5x7 35° 1 1 0.31
4148300274 33 1 2/7 2x7 6x7 40° 2 1 0.31
4148300275 35 1 3/8 2x7 6x7 40° 2 1 0.35
4148300276 38 1 1/2 2x7 5x9 35° 1 1 0.41
4148300277 41 1 3/5 2x7 5x9 35° 1 1 0.42
4148300278 35 1 3/8 2x7 5x9 35° 1 1 0.38
4148300279 36 1 3/7 2x7 5x9 35° 1 1 0.39
4148300280 38 1 1/2 2x7 5x9 35° 1 1 0.41
4148300281 41 1 3/5 2x7 5x9 35° 1 1 0.42



Packaging & Shipping

   Packaging:Carton or Wooden Box





Our Services



KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:

 •Hazardous environment

 •Acts, regulations, and other government guidelines that has to be followed

 •Significant differences in the way people work, mostly due to physical constraints

 •Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour.

 •The best solution with the most reasonable cost is a significant driver



Carbide Tapered Rope Threaded Button BitsCarbide Tapered Rope Threaded Button Bits
