7 Degrees Tapered Drill Chisel Bit

7 Degrees Tapered Drill Chisel Bit thumbnail-1
7 Degrees Tapered Drill Chisel Bit photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
C26-7D-22 to C43-7D-23-4
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing or Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number C26-7D-22 to C43-7D-23-4
Type Other, Tapered Chisel Bit
Material Tungsten Carbide
Use Other, Coal Mining

Specifications

High grade tungsten carbide inserts
Bit bodies manufactured from high grade steel and processed using state-of-the-art CN

Description



Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered chisel bits if the goal is to minimize hole deviation in small hole range drilling. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.



Application



• Dimensional Stone Industry
• Underground Mining
• Tunneling



Specification



<

Part Number Product Code and Brief Description Bit Diameter (mm) Bit Diameter (inch) Tip Size (W x H, mm) Weight (kg)
4148300075 C26-7D-22, 7° Taper Chisel Bit 26 1    10 x 7 0.17
4148300076 C28-7D-22, 7° Taper Chisel Bit 28 1 1/9 10 x 7 0.18
4148300077 C30-7D-22-1, 7° Taper Chisel Bit 30 1 1/6 13.5 x 8 0.22
4148300078 C30-7D-22-2, 7° Taper Chisel Bit 30 1 1/6 13.5 x 8 0.22
4148300079 C32-7D-22-1, 7° Taper Chisel Bit 32 1 1/4 13.5 x 8 0.24
4148300080 C32-7D-22-2, 7° Taper Chisel Bit 32 1 1/4 13.5 x 8 0.24
4148300081 C34-7D-22-1, 7° Taper Chisel Bit 34 1 1/3 13.5 x 8 0.27
4148300082 C34-7D-22-2, 7° Taper Chisel Bit 34 1 1/3 13.5 x 8 0.27
4148300083 C36-7D-22-1, 7° Taper Chisel Bit 36 1 3/7 13.5 x 8 0.3
4148300084 C36-7D-22-2, 7° Taper Chisel Bit 36 1 3/7 13.5 x 8 0.3
4148300085 C38-7D-23-1, 7° Taper Chisel Bit 38 1 1/2 13.5 x 8 0.33
4148300086 C38-7D-23-2, 7° Taper Chisel Bit 38 1 1/2 13.5 x 8 0.33
4148300087 C38-7D-23-3, 7° Taper Chisel Bit 38 1 1/2 15 x 9 0.33
4148300088 C38-7D-23-4, 7° Taper Chisel Bit 38 1 1/2 15 x 9 0.33
4148300089 C40-7D-23-1, 7° Taper Chisel Bit 40 1 4/7 13.5 x 9.2 0.38
4148300090 C40-7D-23-2, 7° Taper Chisel Bit 40 1 4/7 13.5 x 9.2 0.38
4148300091 C40-7D-23-3, 7° Taper Chisel Bit 40 1 4/7 13.5 x 9.2 0.38
4148300092 C40-7D-23-4, 7° Taper Chisel Bit 40 1 4/7 15 x 9.8 0.38
4148300093 C40-7D-23-5, 7° Taper Chisel Bit 40 1 4/7 15 x 9.8 0.38
4148300094 C40-7D-23-6, 7° Taper Chisel Bit 40 1 4/7 15 x 9.8 0.38
4148300095 C40-7D-23-7, 7° Taper Chisel Bit 40 1 4/7 15 x 9.8 0.38
4148300096 C40-7D-23-8, 7° Taper Chisel Bit 40 1 4/7 15 x 9.8 0.38
4148300097 C42-7D-23-1, 7° Taper Chisel Bit 42 1 2/3 13.5 x 9.2 0.41
4148300098 C42-7D-23-2, 7° Taper Chisel Bit 42 1 2/3 13.5 x 9.2 0.41
4148300099 C42-7D-23-3, 7° Taper Chisel Bit 42 1 2/3 13.5 x 9.2 0.41
4148300100 C42-7D-23-4, 7° Taper Chisel Bit 42 1 2/3 13.5 x 9.2 0.41
4148300101 C42-7D-23-5, 7° Taper Chisel Bit 42 1 2/3 15 x 9.8 0.41
4148300102 C42-7D-23-6, 7° Taper Chisel Bit 42 1 2/3 15 x 9.8 0.41
4148300103 C42-7D-23-7, 7° Taper Chisel Bit 42 1 2/3 15 x 9.8 0.41
4148300104 C42-7D-23-8, 7° Taper Chisel Bit 42 1 2/3 15 x 9.8 0.41
4148300105 C43-7D-23-1, 7° Taper Chisel Bit 43 1 2/3 13.5 x 9.2 0.42
4148300106 C43-7D-23-2, 7° Taper Chisel Bit 43 1 2/3 13.5 x 9.2 0.42
4148300107 C43-7D-23-3, 7° Taper Chisel Bit 43 1 2/3 15 x 9.8 0.42
4148300108 C43-7D-23-4, 7° Taper Chisel Bit 43 1 2/3 15 x 9.8 0.42
