China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit

China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit thumbnail-1
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit thumbnail-2
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit thumbnail-3
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit thumbnail-4
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit photo-1
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit photo-2
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit photo-3
China Good Quality/3"-12" Hign Pressure DTH Hammer and Bit photo-4
US$ 50 - 600 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Miroc
Model Number:
DTH hammer and button bit, QL60, SD40-80, CIR90, DTH340 ETC
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB TianJin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Miroc
Model Number DTH hammer and button bit, QL60, SD40-80, CIR90, DTH340 ETC
Type Other, DTH hammer and bit, dth hammer bit
Material Tungsten Carbide
Use Other, mining underground construction water drilling, Tunneling,Mining,Quarrying,Construction

Specifications

High grade tungsten carbide inserts
Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC



Product Description



In DTH drilling, the rock drilling bit is a continuation of the shank, which the rock drill piston strikes directly. Since the piston is in direct contact with the drill bit, little energy is lost. This gives DTH drilling a nearly constant penetration rate regardless of hole length.

DTH bits are paired with their corresponding hammers (by drilling hole diameter and spline configuration). Customers can customize their DTH bits in various ways, such as changing the tungsten carbide insert profile (spherical, ballistic, etc.), face profile (flat face, concave, convex, etc.), and flushing holes.

• Medium to large size drilling diameters
• Works in high pressure range, capable of drilling deep hole lengths





Product Name:

 rock drill tungsten carbide DTH button bits





Description:

rock drill tungsten carbide DTH button bits

DTH button bit are used for blast hole drilling.

Working with DTH hammer, mainly applied in Mining,

Marble quarry or well drilling and other construction projects.

Material:

High quality carbide and High quality carbon steel

MOQ:

No requirement for testing and trial order

Compatibility Series:

COP/ SD/ DHD/ IR/ Mission/ QL/ BR/ CIR etc









China Good Quality/3"-12" Hign pressure DTH Hammer and bit



Applications of  DTH Bit

• Underground mining
• Tunneling

•  Quarry benching operations



Competitive Advantage

• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment





Specification of DTH Bits



Part Number

Product Code and Brief Description

Flushing Holes

Diameter (mm)

Weight (kg)

Gauge Buttons ( No.x mm)

Front Buttons ( No. x mm)

DTH Hammer

4148301682

DTH65PQ

1

68 - 72

1.5

4 x12

3 x 12

DTH65

4148301683

DTH75PQ

3

75 - 77

2.4

5 x 12

3 x 12

DTH70

4148301684

DTH76PQ

2

76 - 78

2.5

5 x 12

3 x 12

DTH76

4148301685

DTH76-78

2

78 - 82

2.6

5 x 12

3 x 12

DTH76

4148301686

DTH80PQ

3

82 - 84

3

5 x 12

6 x 12

DTH80, DTH80X

4148301687

DTH90A

3

90 - 95

3.6

6 x 14

4 x 12

DTH80, DTH80X

4148301688

DTH80XD-90

3

90 - 95

3.4

6 x 12

4 x 12

DTH80XD

4148301689

DTH80-II-80

3

80 - 82

3

5 x 12

4 x 12

DTH80-II

4148301690

DTH90B

3

90 - 95

3.8

6 x 14

4 x 12

DTH90, DTH90-I

4148301691

DTH90T1

2

90 - 95

3.6

6 x 14

1 x 12, 3 x 12 (Spherical)

DTH90, DTH90-I

4148301692

DTH90T2

2

90 - 95

3.8

6 x 14 (Spherical)

4 x 12 (Spherical)

DTH90, DTH90-I

4148301693

DTH90T3J

3

90 - 95

3.6

6 x 14 (Ballistic)

4 x 12 (Ballistic)

DTH90, DTH90-I









Company Profile



KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:

  • Hazardous environment
  • Acts, regulations, and other government guidelines that has to be followed
  • Significant differences in the way people work, mostly due o physical constraints
  • Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver. China Good Quality/3"-12" Hign pressure DTH Hammer and bit
