Zinc Alloy ANSI Mortise Smart lock
We are professional in Electronic Door Lock System, and we can provide various Electronic Door Locks, such as MF1 Electronic Door Lock, Temic Card Electronic Door Lock, IC Contact Electronic Door Lock, TCP/IP Network Electronic Door Lock, Wireless Door Lock...... Zinc Alloy Smart Card ANSI Mortise Electronic Door Lock
Introduction:
L823-M is Zinc-alloy made with surface satin pearl nickel for hotel lock management system.
Features:
- Zinc-alloy, satin pearl nickel.
- RFID M1® technology, 100,000 times write life for keycard, contactless reading keycard.
- ANSI mortise.
- Free-engage while locking.
- Powered by AA battery, easy replace new.
- Openings 20,000 times for one new battery pack
- Audit trail records the latest 800 lock transactions.
- Low Battery Voltage warning (beep and red light).
- Passage mode activate by passage card for meeting case.
- Do not disturb (DND) function for hotels: While thumb turn is on from inside, the lock will refuse the keycard outside by show red light
- Panic release function: the deadbolt and latch are automatically retraced by inside handle shaking to easy egress when emergency happens
- 40mm-50mm thickness door
- Each hotel lock equipped double clock, control the guests check-in and departure time accurately, Make your management of rooms easily.
SPECIFICATIONS:
Power |
LR6 (AA)battery x 4pcs |
Low power alarm voltage |
4.8V |
Communication |
13.56MHz RFID (with keycard)/infrared (with Handheld). |
Card support |
MF1® S50 plus S70 |
Working Distance |
45mm Max |
Working Temperature |
0-60°C |
Working Humidity |
15~85%RH |
Static current |
< 30uA |
Working current |
< 150mA |
Memory |
800 Transactions include Time/Date/Card ID/Card type/Room ID |
Gross Weight |
3.8KG |
Package |
9pcs/Carton at 74.0X44.0X39.0CM |
Content |
Front/Back panel,mortise,cylinder,keyx2,battery-pack,manual/Strike (no battery included, no card) |
Dimension
Product Photo
Product Certification
Our Factory
Our Advantage
1. Professional R&D department, can offer you OEM/ODM services;
2. Professional technique supports and good service;
3. We strictly control the quality and regard it as our base for existence! QC staffs make piece-by-piece checks for all products.
Products are conducted aging test for 72 hours.
4. Our products are chosen high quality materials and ensure the prophase stability.
5. Our products meet ISO, CE, FCC, ROHS certificates;
The MOQ
We accpet sample and bulk order, usually has No specific request. PLS contact our sales for details.
Payment Method
We accept Bank T/T, Paypal, Westerm Union, moneygram and Escrow.
Shipping Method
1. By Express courier, such as: DHL, Fedex, UPS, TNT, EMS... take about 3-7 days.
2. By Air or Sea shipment for heavy and big goods, take longer time differently.
3. By China post for small package, take about 15-70 days.
Product Warranty
We provide 1~2 years warranty from the date of delivery but lifetime technical support.
