HASl LF UL Certificate 94v0 Aluminum Pcb Board for Led
- Shenzhen/HongKong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | RayPCB | |
| Base Material | Aluminum | Copper Thickness | 70um | |
| Board Thickness | 1.6mm | Min. Hole Size | 0.6 mm | |
| Min. Line Width | 0.3 mm | Min. Line Spacing | 0.3 mm | |
| Surface Finishing | HAL |
Product Description
Aluminum PCB for LED lighting
PCB Circuit Board
Competitive Advantage:
Good Pricing |
No MOQ & Free Sample |
Quick Delivery |
Good quality & International Approvals |
Great Customer Service |
On-time delivery |
Diversified Shipping Method |
Wide Range of PCB Supplying |
SMT and thru-hole assembly |
One Stop Turnkey EMS Service |
NO | ITEM | Technical capabilities |
1 | Layers | 1-20 layers |
2 | Max. Board size | 508×610 mm |
3 | Min. board Thickness | 2-layer 0.12mm |
4-layer 0.4mm | ||
6-layer 0.6mm | ||
8-layer 0.90mm | ||
10-layer 1mm | ||
4 | Min. line Width/Space | 0.127mm(4mil) |
5 | Max. Copper thickness | 5OZ |
6 | Min. S/M Pitch | 0.075mm(3mil) |
7 | Min. hole size | 0.15mm(6mil) |
8 | Hole dia. Tolerance (PTH) | ±0.05mm(2mil) |
9 | Hole dia. Tolerance (NPTH) | +0/-0.05mm(2mil) |
10 | Hole position deviation | ±0.05mm(2mil) |
11 | Outline tolerance | ±0.10mm(4mil) |
12 | Twist & Bent | <0.7% |
13 | Insulation Resistance | 100MΩ Normal |
14 | Electric strength | >1.3kv/mm |
15 | S/M abrasion | >6H |
16 | Thermal stress | 288°C 20Sec |
17 | Test Voltage | 50-300V |
18 | Min. blind/buried via | 0.15mm (6mil) |
19 | Surface Finished | HAL, ENIG, OSP, Plating AG, Plating gold,HAL tin, silver |
20 | Materials | FR4,H-TG,Teflon,Rogers,Ceramics,Aluminium, Copper base, CEM-3, CEM-1, Halgenfree |
Product photo:
1.PCB Favricate
2. buy components
3.assembly components
4. PCB layout if provide the schematic
5.Copy PCB Board if provide sample
6.Test PCB ,PCBA funcation if provide test method.
About us :
Our company webiste :
RayMing Technology Co.,Ltd was founded in 1997, is a high-teach enterprise specializing in the production of high-level,high-precision printed circuit boards. We have more than 10,000 square meters,with more than 500 professional employees,monthly capability is 20,000sqm,5000types.
Advantages:
1. With 15 years experience in PCB industry, we can manufacture high quality and competitive price products;
2. Specialized in 1-28 layers boards in prototype, quick-turn and small-medium, which including High Frequency, HDI, Impedance Controlled Board and Heavy Copper PCBs and etc;
3. The shortest lead time for double-sided board in 24 hours, and for 4-10 layers board 48 hours;
4. Obtained the certification of ISO9001,ISO14000, TS16949, ROHS,UL and SGS. All products strictly comply with IPC class 2,and can meet you Class3.
Please send us PCB files or gerber data so that we can quote for you
