Escalator With Degree 30 and 35

Name: Escalator With Degree 30 and 35
Brand: INTENTEC
SKU: 119045951
Availability: InStock

Shenyang Amte Import & Export LLC

US$ 10,000 - 30,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

INTENTEC

Model Number:

FT-001

Payment & Shipping

Payment Methods:

Port of Shipment:

DALIAN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name INTENTEC

Model Number FT-001

SPECIFICATIONS

Escalator with degree 30 and 35

ANGLE OF INCLINATION(°)	30	35
RISE HEIGHT(M)	≤16	≤12
STEP WIDTH(MM)	600/800/1000	600/800/1000
QUANTITIES OF HORIZONTAL STEPS	2/2, 3/3	2/2, 3/3
EUNNING SPEED(M/S)	0.5	0.5
POWER SUPPLY	380V,50HZ,3-phase	380V,50HZ,3-phase
BALUSTRADE	TEMPERED GLASS(THICKNESS:10MM)	TEMPERED GLASS(THICKNESS:10MM)
HANDRAIL BRACKET	BLACK:STANDARD:OPTIONAL*	BLACK:STANDARD:OPTIONAL*
BALUSTRADE HEIGHT(MM)	STANDARD:HAIRLINE STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY	STANDARD:HAIRLINE STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY
INNER&EXTERIOR DECKING PLATE	900/1000(PUBLIC TRANSPORT)	900/1000(PUBLIC TRANSPORT)
SKIRTING	STANDARD:HAIRLINE STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY	STANDARD:HAIRLINE STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY
STEP	STANDARD:STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY	STANDARD:STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY
ENTRANCE LANDING PLATE	STANDARD:STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY	STANDARD:STAINLESS STEEL;OPTIONAL:ALUMINUM ALLOY
LLLUMINATION	LIGHING UNDER UPPER&LOWER LANDING STEPS	LIGHING UNDER UPPER&LOWER LANDING STEPS
INDICATIORS	FAILURE CODE INDICATOR ON CONTORL LANDING STEPS	FAILURE CODE INDICATOR ON CONTORL LANDING STEPS
OPERATION	KEY SWITCH/INSPECTION OPERATION/EMERGENCY STOP BUTTON	FAILURE CODE INDICATOR ON CONTORL LANDING STEPS
