Small Paper Tube Making Machine SKPJ4-20

Small Paper Tube Making Machine SKPJ4-20 photo-1
Small Paper Tube Making Machine SKPJ4-20 photo-2
Small Paper Tube Making Machine SKPJ4-20 photo-3
Small Paper Tube Making Machine SKPJ4-20 photo-4
Small Paper Tube Making Machine SKPJ4-20 photo-5
Small Paper Tube Making Machine SKPJ4-20 photo-6
US$ 1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Product Type:
Paper Core Machine
Processing Type:
Winding Machine
Place of Origin:
Jiangxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Product Type Paper Core Machine
Processing Type Winding Machine
Place of Origin Jiangxi, China
Brand Name Hengda
Model Number SKJP4-20
Voltage 220V/380V/440V
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Auotmatic Parallel Paper Tube Machine, Tube Inner Diameter from 9mm to 500mm.





Features:



1, Directly make the jumbo roll into paper tube and cut tubes into needed length,convenient for regulating tubes’ length.



2, Automatic paper edge grinding device with the machine,benefit for sealing paper tube’s outer circle.



3, Adopt scraping glue way to glue the paper, use scraping plate to scrape the glue,uniformly glue the paper, no glue adhere at the outer cycle of paper tube.



4, Adopt liquid level control, automatic pump the glue.



5, Adopt the workmanship of waxing inner circle of paper tube, reduce the resistance of discharging tube and keep no glue at the inner circle of the paper tube.



6, The glue vessel is adopted stainless steel design,acid corrosion.



7, Electric components and pneumatic components use importing famous brand with high quality.



8, Reeling tube’s motor, conveying paper’s motor and discharging tube’s motor are all adopted servo motor with high precise and fast speed.



9, Every action adopts numerical control, highly automatic to let the machine run stably and keep high production capacity.



10, Adopt touch screen design, easy to operate and set the parameter, convenient for finding malfunction.







Technical Parameter:



Max. Paper tube length (The width of reel paper): 620mm

Max. Diameter of reel paper: 1300mm

Paper tube inner diameter:4-20mm

Paper tube thickness: 1-6mm

Applicable paper grammage: 70-550gsm

Production speed: 30-36pcs/min

Dimension: 4500 x 950x1400mm
