200A dc portable upvc corner welding machine
Why Choose mig/tig welding welder?
1. Are you afraid of tungsten inclusion?
With high frequency arc ignition, this mig/tig welder can avoid tungsten inclusion
2. Do you want to achieve high quality welding effect?
With both pre and post gas supply, especially with adjustable post gas supply time to insure welding quality.
3. Do you want to get both hand welder & MIG welding machine?
This is a all-in-one hand welder and mig/tig welder
4. Do you often move it or do you want it to be lighter?
With light weight, this mig/tig welder is easy to move
5. Are you scared by frequent failure?
This mig/tig welder is of simple structure and low failure rate. You are free from worry.
Technical Specification:
| 200A dc pvc hot air welder gasoline | ||
| Type | AXQ1-200T | |
| Welder | No-load Voltage (V) | 60-85 |
| Rated-load Voltage (V) | 22–28 | |
| Welding Output Current (A) | 40–200 | |
| Welding Rod Diameter (Φmm) | 1.2-5 | |
| Welding Method | Hand Welder, MIG Welder | |
| Duty cycle (%) | 100 | |
| Auxiliary power supply | DC220v/3kw | |
| TIG welder arc striking gap (mm) | ≥5 | |
| Argon arc welding current (A) | 10-200 | |
| Pre gas supply(S) | 3 | |
| Post gas supply (S) | 3~8 adjustable | |
| Frequency | High frequency | |
| Engine | Engine Model | KOHLERCH440, B&S2552 (optional) |
| Valve Type | OHV | |
| Displacement | 389 | |
| Ignition system | CDI | |
| Fuel Tank Capacity (L) | 25 | |
| Fuel Consumption (g/HP.hr) | 228 | |
| Oil alarm system | YES | |
| whole set | starting system | Recoil |
| Insulation Class | H | |
| Protection Class | IP21 | |
| Dimensions (mm) | 680×530×605 | |
| Net weight(kg) | 68 | |
Application Scope:
This 200A dc welding machine is be used to weld railway tracks, guard rails, natual gas pipes, oil pipelines, and all kinds of black metals.
Permanent Magnet Generators:
Contact Us:
Skype: amysales12
WhatsApp/Wechat: +8618223170017
