Home > Products > Generator welder > Trailer portable Chinese diesel powered +weichai WP2 engine welder generator
Trailer portable Chinese diesel powered +weichai WP2 engine welder generator
- 1000 Set / Sets per Month
- Chongqing
- T/T Credit Card
Product Details
Condition: | New | Place of Origin: | Chongqing, China | Brand Name: | YOHOU |
Model Number: | AXC1-400 | Arc Current: | 400A | Pulse Frequency: | 720HZ |
Pilot Arc Current: | 40-400 A | Rated Duty Cycle: | 60% | Motor Type: | AC Motor |
Dimensions: | 2200*950*1100mm | Usage: | All kinds of black metals | Voltage: | 22-36v |
Power(W): | 12kw | Certification: | CE CCC | Warranty: | 2 years |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Trailer portable 12KW/400A Chinese diesel powered welder generator
Description:
This trailer portable Chinese diesel powered welder generator is equipped with an intermediate frequency Chinese generator, a Kohler diesel engine and an ac dc welder. With trailer mounted, this portable Chinese diesel welder generator is sutiable for outdoor working.
Features:
- Powered by Weichai diesel engine, with higher safety
- With patented magnet induction control system to prevent electrical components deterioration, lower failure rate
- With initiating excitation system to avoid losing excitation
- With trailer mounted
- Both AC and DC output
- Large standby power
Specifications:
Model | AXC1-400 | |
Welder
| No-load Voltage (V) | 60-85 |
Working Voltage (V) | 22-36 | |
Electric current range (A) | 40-400 | |
Duty cycle(%) | 100 | |
Welding Rod Diameter (mm) | 2-8 | |
Three Phase Output | AC400V/12KW | |
Standby Power | AC230V/8KW | |
Insulation Class | F | |
Engine
| Engine Model | WEICHAI 2.5D22F2 |
Displacement(CC) | 2540 | |
Fuel Tank Capacity (L) | 60 | |
Fuel Consumption (g/HP.hr) | 235 | |
Oil ALERT system | YES | |
Starting System | Electric Start | |
Whole Set
| Protection Grade | IP25 |
L×W×H(mm) | 2200*950*1100 | |
Net weight (KG) | 560 |
Send inquiry to know more about this generator
MS ELEVEN HUANG Mob&whatsapp: 0086-136 3541 0407
TEL:0086-23-6861 5411 FAX:0086-23-6844 5314
WEBSITE: www.zqzhiren.en.china.cn
24-hour service :400-0023-027
