Galvanized Steel Bar Grating Lighting Weight Drainage Trench

Name: Galvanized Steel Bar Grating Lighting Weight Drainage Trench
Brand: Yuntao
SKU: 119007239
Availability: InStock

Hebei Yuntao Trading Co., Ltd.

Galvanized Steel Bar Grating Lighting Weight Drainage Trench thumbnail-1

Galvanized Steel Bar Grating Lighting Weight Drainage Trench photo-1

US$ 10 - 50 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Hebei, China

Material:

Other, Galvanized Steel Sheet, Low carbon steel sheet.

Type:

Welded Mesh

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang Port of China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hebei, China

Material Other, Galvanized Steel Sheet, Low carbon steel sheet.

Type Welded Mesh

Application Filters

Weave Style Other, welded

Wire Diameter 20*3mm,25*3mm,30*3mm etc

Technique Welded Mesh

Model Number YT-33

Brand Name Yuntao

Specifications

steel grating weight
Load bar:20*3mm,25*3mm,30*3mm etc
Cross bar diameter:5mm
Size:1m*2m/piece
Shape:Round,square etc

steel grating weight:

Galvanized Steel Grating is a kind of open steel member with its bearing bars & cross bars jointing at their intersections either by welding or by locking.

Galvanized Steel Grating is made by stainless or mild steel of certain sizes through the processing of grooving, lock-pressure, welding, finishing and other treatment. Industrial bar gratings can be actually made from copper, aluminum and other materials, while galvanized Steel Grates is the mostly used one due to its economic cost and good property.

General Usage of Galvanized Steel Grating:

Flooring	all kinds of Trench cover
Catwalk	Window and machinery safe guards
Mezzanines/decking	Wash rack
Stair tread	Ventilation screen
Fencing	Storage rack
Vault bin floor	Suspended ceiling
Ramp

Galvanized Steel Grating Panels Types:

There are three kinds of steel gratings distinguished by different bearing bar types. The respective of features are as follows:

1) Plain: the most widely used gratings,available for flooring sidewalk,all kinds of ditch cover,stair tread,etc.

2) Serrated:best non-skid property & safety compared with plain grating.

3) I-shape:lighter,Not substantially weaken the case of load capacity more economical and practical comparing with plain grating.

The Most Popular Specification of galvanized Steel Grating:

1) Steel grating with 30mm bearing bar pitch is the most widely used in industrial area.Among the general series.it maintains the strongest resistance to impulsive force.

2) Steel grating with 40mm bearing bar pitch is one of most ecnomical & lightest types.It should be the best choice to customer on the occasion when the clear span is small.

The normal specifications we manufacture:

Cross Rod Pitch	load Bar Pitch	load Bar Specification(Width×Thickness)
Cross Rod Pitch	load Bar Pitch	20×3	25×3	32×3	40×3	20×5	25×5
30	100	G203/30/100	G253/30/100	G323/30/100	G403/30/100	G205/30/100	G255/30/100
30	50	G203/30/50	G253/30/50	G323/30/50	G403/30/50	G205/30/50	G255/30/50
40	100	G203/40/100	G253/40/100	G323/40/100	G403/40/100	G205/40/100	G255/40/100
40	50	G203/40/50	G253/40/50	G323/40/50	G403/40/50	G205/40/50	G255/40/50
60	50	-	G253/60/50	G253/60/50	G403/60/50	G205/60/50	G255/60/50
Cross Rod Pitch	load Bar Pitch	load Bar Specification(Width×Thickness)
Cross Rod Pitch	load Bar Pitch	32×5	40×5	45×5	50×5	55×5	60×5
30	100	G325/30/100	G405/30/100	G455/30/100	G505/30/100	G555/30/100	G605/30/100
30	50	G325/30/50	G405/30/50	G455/30/50	G505/30/50	G555/30/50	G605/30/50
40	100	G325/40/100	G405/40/100	G455/40/100	G505/40/100	G555/40/100	G605/40/100
40	50	G325/40/50	G405/40/50	G455/40/50	G505/40/50	G555/40/50	G605/40/50
60	50	G325/60/50	G405/60/50	G455/60/50	G505/60/50	G555/60/50	G605/60/50

Pictures:

Barbed Wire Normal Specification
Type	Wire Gauge (SWG)	Barb Distance (cm)	Barb Length (cm)
Electro Galvanized Barbed Wire; Hot-dip zinc plating barbed wire	10# x 12#	7.5-15	1.5-3
	12# x 12#
	12# x 14#
	14# x 14#
	14# x 16#
