Specifications
Thermal padsWidely used to heat transfer between heat-generating system and heat sinks, or other cooling devices.
Thermal Pads
LD8080 is a thermal gap pad which is designed to provide heat-transfer path between heat generating to heat sinks or other cooling devices(fans,heat pipes,metal cases).LD8080 offer slightly tacky on both sides.
Features&Benefits:
-Thermal conductivity:0.8w/m.k
-Slightly tacky on both sides
-Electrical isolating
-Conformable gap filler material at low stress application
-Cost effective
Typical Application Includes:
-LED Lighting
-Power Supply
-Low power modules,like NB and DT memory
-DIM Modules
-Power conversion
-Between semiconductor/magnetic components and heat sinks.
Configurations:
-Sheet form,die-cut parts
-Tape application available
Size available:
200x400mm
Thickness available:
0.25mm,0.3mm,0.5-18.0mm,increment by 0.5mm
Properties:
Typical Properties of Gap Pad LD8080 | |||
Property |
Unit |
Metric Value |
Test Method |
Color |
*** |
White Grey |
Visual |
Thickness |
mm |
0.5~2.0 |
ASTM D374 |
Density |
g/cc |
2 |
ASTM D792 |
Hardness |
Shore C |
20±5 |
ASTM D2240 |
Tensile Strength |
KN/m |
1.6 |
ASTM D412 |
Continuous Use Temp. |
°C |
-40-150°C |
EN 344 |
Electrical | |||
Breakdown Voltage |
Kv/mm |
≥4.0 |
ASTM D149 |
Volume Resistivity |
Ω.cm |
1.7×1016 |
ASTM D257 |
Flame rating |
V-0 |
V-0 |
UL 94 |
Thermal | |||
Thermal Conductivity |
W/m.k |
0.8 |
ASTM D5470 |
For more details and application direction,welcome to contact our sales!
