Specifications
1.Circular conveyor belt2.Good quality
3.Best price
4.Sample free
5.Min 100 meters
Endless conveyor belt with sidewall Circular conveyor belt
Quick Details
- Place of Origin: Hebei, China (Mainland)
- Brand Name: TRX
- Material: Rubber
- Width: 300mm - 2500mm
- Tensile Strength: 10Mpa to 25Mpa
- Thickness: 3mm to 50mm
- Ply: 2-6
- Edge: Molded Edge / Cut Edge
- Fabric cloth: EP, NN or Cotton
- Elongation: 400%
- Standards: DIN, GB, RMA, JIS, BS, AS, SABS
Specifications
Endless conveyor belt is conveyor belt that has been made into endless without joint in the process of production.
Endless Conveyor Blets With Sidewall
Description:
It is based in the following main components:
(1) Cross-stabilized Base Belts
(2) Sidewalls
(3) Cleats
Sidewall Conveyor belt has been designed with two corrugated sidewalls and cleats molded to cross-rigid base belt can carry heavy product loads up to the inclined angle of 75°. This belt is popular where space is at a premium and steep incline angles are desired.
The Base Belt:
The base belt is designed to bend efficiently in a longitudinal direction and has greater rigidity in a transverse direction by utilizing reinforced fabrics with monofilament, creating a fabric carcass of high tension.
Features :
Cross Rigid Conveyor Belt can be deflected from the horizontal to an incline or vertical and back again without bowing or sagging. These deflection points as well as the belt returning on free lateral space by snub idlers definitely require the cross-rigidity of the base belt. The designed mono-filament fabrics provide better returnside support, no wear and tear of cleat and cover rubber is available with various compounds like abrasion resistance oil, heat, and flame resistance.
1. 90 degree inclination
2. High load
3. Save space
Advantage:
- Fabric is twinning without joint
- Surface of the belt is smooth and even in tension
- Low elongation at work
- Long service life
Application:
- Mobile Crushing, Screening and Recycling Sectors
- Metallurgy, Coking Steel
- Cement
- Milling Machine, etc
