Specifications
1' 220V AC 50hz 3 phase2' Pulse and analog control
3' rated power 100w
4' USB interface, MODBUS
5' CE, ISO, TUV
Small single phase ac servo amplifier 220V
About us
All-digital AC servo motor motion control driver and servo motor have been researched for 20 year and been produced for 10 years by us. It is believed that good quality products and service could be offered for you.
About this product
A.Introduction
Designed and produced by market demand, EP3 series Multifunctional AC Servo motor motion control driver adopts advanced control algorithm and intelligent power module (IPM), which could realize precise digital control on torque speed and position. Designed on the basis of EP2 series, functions of USB Interfaces , sustaining Modbus agreement and internal simple PLC are added. This series includes 3-phrase 220V series and 3-phrase 380V series. The feedback mode is 2500 line incremental encoder or 17 bit absolute encoder, which could support 16 bit current sampling and 16 bit external analogue sampling accuracy. Thus, it owns advantages of strong overload capacity, fast response, easy operation without setting driver code. The selected exquisite operation panel could do the realtime monitor and adjust the operating situation of motors. Designed on the reliability requirement of domestic industrial environment, it helps to make the stability of products reliable.
B.New function
a. Position control mode
b. Simulation command control
c. Resonance inhibition
d. PLC Function
e. Defensive function
f. Modbus Interfaces
g. USB PC Interfaces
h. Signal output of Encoder
C. Features
a. realize precise digital control on torque speed and position
b. support 16 bit current sampling and 16 bit external analogue sampling accuracy
c. strong overload capacity, fast response, easy operation without setting driver code
D. Scope of application
a. CNC industry
b. Textile industry
c. Printing and packaging industry
d. Robot industry
e. Mechanical spring machine industry
f. Paper making industry
g. Industrial spring machine
E. Main Markets
a. Asia
b. Europe
c. Middle East
d. South America
e. North America
f. Oceania
g. Africa
F. Technical parameters
| Model | GL 1A0 | GL 3A0 | GL 7A5 | GL 120 | GL 160 | GL 190 | GL 240 | GH3A5 | GH 5A4 | GH 8A5 | GH 130 | GH 170 | ||
| Rated output Power(kW) | 0.1 | 0.4 | 1 | 1.5 | 2 | 3 | 5 | 1 | 1.5 | 2 | 3 | 5 | ||
| Rated output current(A) | 1 | 3 | 7.5 | 12 | 16 | 19 | 24 | 3.5 | 5.4 | 8.5 | 13 | 17 | ||
| Input power | Main supply | 1-phase 220VAC -15%~+10% 50/60Hz | 3-phase 220VAC -15% +10% 50/60Hz | 3-phase 380VAC -15%~+10% 50/60Hz | ||||||||||
| Control supply | 1-phase 220VAC-15%~+10% 50/60Hz | 24VDC±15% ≥1.5A | ||||||||||||
| Environment | Temperature | Working:0°C~ 40°C Storing:-40°C~ 50°C | ||||||||||||
| Humidity | Working:40% ~ 80%(non condensing) Storing:under 93%(non condensing ) | |||||||||||||
| Atmospheric Pressure | 86kPa ~ 106 kPa | |||||||||||||
| Protection Level | IP20 | |||||||||||||
| Control Mode | vector control | |||||||||||||
| Regenerative Braking | Built-in/built-out | built-out | ||||||||||||
| Feedback Mode | 2500 line incremental encoder or 17 bit absolute encoder | |||||||||||||
| Control Mode | Position, speed, torque, position/ speed,speed/torque,position/torque | |||||||||||||
| Digital input | 5 Programmable input terminals(Optical Isolation) | |||||||||||||
| Digital Output | 3 Programmable input terminals(Optical Isolation) | |||||||||||||
| Position | Input Frequency | differential input:≤500kHz(kpps), single-ended input:≤200kHz(kpps) | ||||||||||||
| instruction mode | Pulse+Signal,CCW Pulse/CW Pulse, Two-phase A/ orthogonal Pulse | |||||||||||||
| Electronic Gear Ratio | 1 ~ 32767/1 ~ 32767 | |||||||||||||
| Speed | Simulation command input | -10V ~ +10V,input impedance10kΩ | ||||||||||||
| Instructions Acceleration And Deceleration | Parameters set | |||||||||||||
| Instructions source | analog,Internal speed instructions | |||||||||||||
| Torque | Simulation command input | -10V ~ +10V,input impedance10kΩ | ||||||||||||
| Speed restriction | Parameters set | |||||||||||||
| Instructions source | analog,Internal torque instructions | |||||||||||||
| Special Functions | ZRN ,Gain switch,mechanical resonance wave trap, sustaining Modbus agreement | |||||||||||||
| Surveillance Function | Revolving Speed,Current Position,Positional Deviation,Motor Torque,Motor Current,Instructions Pulse Frequency etc. | |||||||||||||
| Defensive function | Overspeed,Overvoltage,Overcurrent,Overload,Abnormal brake,Abnormal Encoder,out of tolerance etc. | |||||||||||||
| Feature | Speed Frequency Response | ≥300Hz | ||||||||||||
| Speed Fluctuation Rate | <±0.03%(load 0 ~ 100%); <±0.02%(power-15% +10%) | |||||||||||||
| Speed Ratio | 3.513889 | |||||||||||||
G. model
H. Size
I. producing and packaging procedure
J. Certifications
a. Quality Management System Certification
b. HI-tech Enterprise certification
c. Patent for Invention: a kind of device and method of alterable encoder output lines
K. Our favorable Service:
a. The fewest MOQ is offered. You can purchase 1 set for testing before you place a big order. We will send samples by express like DHL or Fedex.
b. A variety of special specifications for customized products could be provided for customers with comprehensive solutions.
c. Welcome to visit our company.
d. For more information about our products,please feel free to contact us by email or telephone. Thank you.
