Specifications
1.type:SRL-Z300/600 Plastic Powder Mixing Machine2.total volume:300L
3.power:40/55kw
4.CE certification
5.factory
SRL-Z300/600 Plastic Powder Mixing Machine
Application & Apply Range
It is used in mixing, drying, coloring and other industrial art, it is the ideal equipment for producing profile and pipe.
It is heating mixing has self-friction electric heating
Two layers of sealing is adopted in the pot cover, pot cover of cooling machine adopts arch cover, which can avoic deforming
It has features of contact construction, good performance
They have passed the test of dynamic balance and static equilibrium
SRL-Z300/600 Plastic Powder Mixing Machine ---chart :
SRL-Z300/600 Plastic Powder Mixing Machine--paddles:
SRL-Z300/600 Plastic Powder Mixing Machine---data:
|
Total Volume
|
Hot Mixer:300L |
Cooling mixer:600L |
|
Effective volume
|
Hot Mixer:225L |
Cooling mixer:480L |
|
Thickness and material Of pot wall
|
Hot Mixer:8mm(1Cr18Ni9Ti) |
Cooling mixer:6mm(1Cr18Ni9Ti) |
|
Thickness and material Of pot bottom
|
Hot Mixer:10mm(1Cr18Ni9Ti) |
Cooling mixer:10mm(1Cr18Ni9Ti) |
|
Blade number
|
Hot Mixer:3pcs |
Cooling mixer:1pcs |
|
Blade material
|
Hot Mixer:stainless steel |
Cooling mixer:stainless steel |
|
Blade rotate speed
|
Hot Mixer:475/950rpm |
Cooling mixer:130rpm |
|
Motor power
|
Hot Mixer:40/55KW |
Cooling mixer:11KW |
|
Mixing time
|
Hot Mixer:8~10min/pot |
Cooling mixer:6~8 min/pot |
|
Feeding capacity once
|
110kg |
|
|
Mixing capacity
|
480~550kg/h |
|
|
Heating mode
|
Electric heating and friction |
|
|
Discharging material mode
|
By pneumatic gas cylinder |
|
Pot cover turn on method |
By pneumatic gas cylinder |
|
|
Main electrical apparatus
|
Japan Omron temp. controller,Siemens AC contactor |
|
|
Whisking Blade
|
Adopt high quality stainless steel casting |
|
|
Main axes bearing
|
Adopt high quality Haerbin bearing |
|
Pot cover |
Adopt high quality aluminum casting, Adopt two rubber sealing bar, Pot cover opening by pneumatic gas cylinder |
|
SRL-Z300/600 Plastic Powder Mixing Machine----hot mixer picture:
If you are interested in our machines, please do not hesitate to contact us.
Hope we can succeed in cooperation and establish a long term business relation.
Best regards.
Amy Su
