Specifications
SpecificationsHigh pure aluminum foil tape
1.excellent heat transfering property ,electrical conductivity
2.good insulati
Hot Chinese reflective Aluminium Foil Insulation for roof with pure aluminum foil
- 1. a) Foil: 7μm
b) 2-way scrim: 12.5 x 12.5mm space
c) Polyethylene d) Kraft: 50gsm, natural
- 2. FSK716B: a) Foil: 7μm
b) 2-way scrim: 12.5 x 12.5mm space
c) Polyethylene d) Kraft: 60gsm, natural
- 3. Roll width: 1.0, 1.2, 1.25, 1.30m
- 4. Roll length: 60, 120, 300, 500, 1600, 2750m Technical parameter Data Tenical parameter Data
Aluminum foil Technical Parameters:
Physical Properties |
Test Method |
Values (English) |
Values(Metric) |
Basis Weight |
Scale |
25.5lbs/1000 ft2 |
125g/m2 |
Tensile Strength |
GB/T12914-1991 |
22.5lbs/inch(MD) |
3.79 kn/m(MD) |
13.9lbs/inch(XD) |
2.31 kn/m(XD) |
||
Bursting Strength |
GB/T454-2002 |
36 lbs/psi |
248 kpa |
Water-resitant |
23 °C 24h |
No phenomenon of layered |
No phenomenon of layered |
Low-temperature resistant |
-40 °C 1h |
No phenomenon of layered |
No phenomenon of layered |
High temperature resistant |
116 °C 4h |
No leakage phenomenon |
No leakage phenomenon |
Thickness |
Micrometer |
0.0058 inch |
150 micron |
parameter Data
Delivery Information:
- MOQ: 1X20"FT
- Delivery Time: Within 7-15 days after received advance
- Payment: T/T, L/C, DP & DA and we can discuss.
Product picture show:
,
Our Company Mission:
- Help partners to achieve success.
- Cooperaion wih customers to create a win-win situation.
- We will guarantee the best quality and service let you more satisfied.
When you have free time, welcome to visit our factory any time.
