Factory price t8 led tube light 18w 2160lm High lumen Electronic Ballasts Compatible T8 LED Tube
led t8 light Advantages
1.Aluminum alloy body and PC cover ensure very good heat dissipation & high light transmission .
2.Work without ballasts (100-277VAC)
3.80% energy saving by using ultra -bright LED.
4. Quick-start ,eye protection.
5.Low light decay , long lifetime ,up to 50,000hrs
6.Replacement between our LED tube and traditional fluorescent tube is free and direct.
7.50,000hrs lifespan, standard 3 years warranty, optional 5 years warranty
8.Vibration and impact resistant
9.No mercury allowing for non-hazardous waste materials
10.Instant illumination, no flicker, no buzz
11.No UV emission
led t8 light Specification
Module No. |
Size(MM)
|
Input Voltage(V) |
Power(W) |
Lumens(LM) |
CCT(K) |
CRI(Ra) |
PF |
Beam Angle | Rf.No |
SLT-C08-X0610 |
Φ26/28x600 |
100-277 |
10 |
1200 |
3000/3500/4000/5000 |
80/90 |
0.9-0.95 |
120°-160° |
2835/72 |
SLT-C08-X1212 |
Φ26/28x1200 |
100-277 | 12 |
1650 | 3000/3500/4000/5000 | 80/90 | 0.9-0.95 | 120°-160° | 2835/105 |
SLT-C08-X1215 |
Φ26/28x1200 |
100-277 | 15 | 1800 | 3000/3500/4000/5000 | 80/90 | 0.9-0.95 | 120°-160° | 2835/105 |
SLT-C08-X1218 |
Φ26/28x600 |
100-277 | 18 | 2160 | 3000/3500/4000/5000 | 80/90 | 0.9-0.95 | 120°-160° | 2835/105 |
led t8 light Test Report
Light distribution diagram
T8 1.5M 22W LEDs150 6-60.5k
Light AAI Figure
T8 1.5M 22W LEDs150 6-60.5k
led t8 light Details
led t8 light installation
led t8 light Wiring Diagram
Double-end Power Input Wiring Diagram
led t8 light Regulatory standard
Manufacturing Quality Standard LED Luminaire Standard
ISO 9001:2008 EN/IEC 61347-1
ISO 14001:2004 EN/IEC 61347-2-13
EN/IEC 62348
LED Light Photometric Standard EN/IEC 61000-3-2
IES LDT EN/IEC 61000-3-3
EN/IEC 61547
LED Luminaire Performance EN 55015(CISPR 15)
LM-79-08
LM-80-08
LED Module Standard RoHS Standard
IEC 62031 IEC 62321
Established in 2004, Sichuan Sunfor Light Co., Ltd is a high-tech enterprise dedicated to advanced research and development in LED lighting technologies and rare earth illuminous materials, is a leading company of enterprise spearheads the transition from “ Made in China” to “ Innovated in China”
Equipped with two research and development centers in Semiconductor lighting and rare-earth luminescent materials respectively, up to June 2015, Sunfor Light possess more than 900 international and domestic patented techbologies, including over 120 covered by the patent cooperation Treaty (PCT). Sunfor products have been certified by CQC, UL, CE, RoHS and LM-80, etc.
Sunfor ACLED technology is an worldwide inventing patent, In June 2013, 10 academicians from Chinese Academy of Science (CAS) unanimously agreed that Sunfor’s unique method of using its proprietary rare earth LED luminescent materials, with controllable afterglow life to match up with frequencies of varying alternative currents (ACs) to significantly reduce the stroboscopic effects produced by with LEDs directly driven by ACs can effectively solve the vexing flickering problem beleaguering the LED lighting industry. And, by doing so, Sunfor becomes the world’s first and only company able to produce AC-LED lighting products with low stroboscopic flickers based on rare-earth luminescent phosphors. And this is why ACLED lights are Sunfor core products.
Job references- LED lights
Domestic market : National Grand Theater, Beijing Airport Terminal 3, Beijing Olympic Games, Shanghai Expo, Yili Group, Mengniu Dairy, Metro system in Shenzhen, Guangzhou, Beijing Shanghai and Chengdu, street lights in Changchun, Jilin,Shutong Industrial Park in Nantong, Jiangsu, and Yibin Sichuan,ect.
Oversea market : Starbucks and HSBC Bank in Brazil, hospitals and schools in Barcelona, Spain.
Intelligent and leading
Developing intelligent lighting technology to usher in the a better future for the mankind is one of Sunfor lights’s unyielding pursuits. Sunfor Light believes in developing ergonomic intelligent lighting technology, centered around its user in a controlled luminous environment, to enrich people’ moder life. At home, in offices or leisure facilities, whether day or night, Sunfor light brings fresh lighting experience and joy to people. Using on artificial lighting for plants, Sunfor light is reinterpreting meaning of the old saying of “ the provision of bread is everything”.
