Specifications
Given-bag Fillling and Sealing Machine1. PLC
2. Pneumatic components
3. Temperature Controller
4. Vacuum pump
Pouch Fillling and Sealing Machine
1. Bag type: All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, and block bottom bags, zip-lock reclose able bags, stand-up pouch with or without spout etc.
Model | MR8-200 |
No. of working stations | 8 station |
Bags size | W:80~200mm L:100~300mm |
Filling Volume | 5 – 2500g depending on type of products |
Capacity | 25-55bags/min (The speed depends on the product status and filling weight)) |
Total power consumption | 3.6Kw |
Machine Weight | Approx. 1,000 Kg |
Compress air requirement | 0.6m³/min supply by user |
Machine Features:
1. High quality and performance, the frame is made of 150mm thickness 304# stainless steel.
2. Volume changed easy by adjusting handle in the paste filler.
3. Good stable and also good machine exterior
4. Own extensive range in filling productions
5. Easy operate by touch-sensitive screen (Siemens), PLC (Siemens) and electric control system
6. Friendly man-machine interface
7. Speed can be adjusted by frequency conversion within the range.
8. Perfect sealing system
9. Good safety secure and so on
Safety:
No bag – no filling- no sealing, machine alarm
Bag opening miss- no filling-no sealing, machine alarm
Machine stop or alarm when the air pressure is abnormal
Error position display at the control panel
Control panel locate on the right side top of the machine
Outside of the machine and all the parts which touch production all made by stainless steel.
There are several safety doors made by aluminum Profile Frame.
The doors are equipped with safety proximity sensors
Machine surface can be washed by water and brushed by cloth
For common bag For zipper bag
1.bag feeding 1.bag feeding
ding date ding date
3.opening bag 3.opening zipper
4.filling 1 4.opening bag
5.filling 2(reserve) 5.filling
6.sealing 1 6.close zipper
7.sealing 1 7.sealing 1
8.sealing 2,out putting 8.sealing 2,out putting
...
