Specifications
Automatic Pickles Filling Machine1. PLC
2. Pneumatic components
3. Temperature Controller
4. Vacuum pump
Automatic Pickles Filling Machine
Technical parameters
Model |
MR-x6 |
Bag type |
6 station |
Working station |
1. Giving bag,ding date 3. Opening bag 4. Filling1 ( Pickles )5. Filing 2 ( liquid )6. Sealing (Shaping and output.) |
Size of bag |
Standup bag, portable bag, hand luggage, zipper bag, edging bag, 4sides, edging bag, 3 sides, paper |
Filling scope |
W:70-200mm |
Speed |
40-50bags/min (depending on type of product and packing matial used |
Package accuracy |
Error<=+-1 |
Scope of application |
A variety of pickles |
Compressed air consumption |
0.6m3/min (compressed air provided by the user) |
Application Scope: canned fruit, canned vegetables, liquid materials, the sauce and paste materials
Perfect quality to ensure high-speed and stable production
Adopting high-quality accessories to maintain the lasting stability of the machine
Waterproofing system to make cleaning more lor touch screen let operation more Simple
solving a variety of problems in innovative solutions with reasonable cost.
Working Process:
Station 1 Bag feeding
Station 2 Date Printing (option)
Station 3 Open bag
Station 4 Filling production
Station 5 Sealing .
Station 6 output
1. No bag – no filling- no sealing, machine alarm.
2. Bag opening miss- no filling-no sealing, machine alarm.
3.Machine stop or alarm when the air pressure is abnormal.
4.Error position display at the control panel.
5.Control panel locate on the right side top of the machine.
6.Outside of the machine and all the parts which touch production all madeby stainless steel.
7.There are several safety doors made by aluminum Profile Frame.
8.The doors are equipped with safety proximity sensors.
9.Machine surface can be washed by water and brushed by cloth.
Our Services:
1,How many days can finish install all machine ?
Generally need 1 week, finish all install machine, adjustment and training worker.
2,should we pay any cost for engineer?
Yes, for engineer visa cost, accommodation, food, round air-tickets, and subsidy(100USD/day) by buyer.
3,how about warranty?
One year guarantee, defective spare parts can be replaced for free charge by express within this period.
4,if over warranty how to do ?
If over warranty, we also can do service for customer, send to spare parts by express or our engineer go to your side check and adjust machine. The buyer pay for all charge.
5,do your engineer know english?
Our engineer know english,and every engineer have five years experience adjust, install machine,our engineer have been to USA,South America,Southeast Asia, Europe, Africa etc.
6, how can we solve the problem when machine have problem?
Usually after first install machine,no bigger problem. If it has small problem,we can take video. Meanwhile we can call phone or skype face to face teach your engineer how operation and adjust machine by email.
7 ,how many worker ?
Generally the one machine one worker or two worker.
8 ,When engineer can arrive our factory?
Generally after machine arrived, Within one week reached
We are one of the top manufacturers of packaging machines in China, with more than 10 years experience. Our machines have been sold to many countries around the world, and accessed trust and praises from our customers by our excellent quality, reasonable price and good service.
We have many kinds of package machine, such as rotary package machine and vertical package machine, pillow type package machine and so on. For more information, please see our new website
:
