Specifications
Weather proof under natural destroy, corrosion resistant.Reno Mattress
Reno Mattress (Stone netting,heavy hexagonal, pinch spend net, Gabion network) are wire containers, which are made of hexagonal wire netting.
Gabion Box Wire diameter varies with the hexagonal nettings.
Gabion Box for hexagonal wire netting with no pvc coating, the wire diameter ranges from 2.0mm to 4.0mm.
Gabion Box for those PVC coated hexagonal wire netting, the outside diameter ranges from 3.0mm to 4.0mm.
The diameter of the wire of the outside frame edge is thicker than the one used for hexagonal wire netting.
Reno Mattress Specifications
| Reno Mattress Material: | Low carbon steel wire |
|---|---|
| Gabion Box Applications: |
Control and guide of water or flood Flood bank or guiding bank Preventing of rock breaking Water and soil protection Bridge protection Strengthening structure of soil Protection engineering of seaside area |
Reno Mattress Characteristics:
(1) Economic and useful: What we need to do is just put the stones into the cage without special skills.
(2) It is convenient to transport as it can be transported folded, assembly on site.
(3) It has a strong resistance to natural destruction and poor weather.
(4) It can withstand large-scale deformation, and does not collapse.
(5) Some plants can grow in the gap among the rocks, and it can melt with the natural environment surrounding together.
(6) And it has good permeability, which can prevent the damage caused by fluid static.
Uses of Stone netting: widely used in highways, railways, protecting hillside, hillside greening, well and alley fence, building and breeding, zoo fence, greening fence, hillside net cage, flood fighting net cage, revet fence, control and guide the direction of river, spillway and diversion channel, rock fall protection, prevent soil and water from flowing, beach protecting project, protection of the bridge, solid structures defense project, retaining wall, and port.
( Reno Mattress Standar Size:( customers can send inquiry as the below sheet for reference)
Table 1 mesh characteristics
Characteristics |
Gabion |
|
Metallic coated |
PVC coated |
|
Mesh type opening |
8 by 1083 by 114 mm(3.25 by 4.5 in.) |
8 by 1083 by 114 mm(3.25 by 4.5 in.) |
Mesh wire |
2.4/2.7/3.0mm |
2.4/2.7mm |
Selvege wire |
3.0/3.4/3.8mm |
3.0/3.4mm |
Lacing wire |
2.2mm |
2.2mm |
Fasteners |
3.0mm |
3.0mm |
Stiffeners( using lacing wire ) |
2.2mm |
2.2mm |
Preformed |
3.8mm |
3.4mm |
PVC coating thickness: Nominal |
N/A |
0.5mm |
Minimum |
N/A |
0.38mm |
Table 2 typical Gabion Mesh size (m)
Length |
Width |
Height |
No. |
Volume M3 |
Meter |
Meter |
Meter |
Each |
ter |
2.0 |
1.0 |
1.0 |
2.0 |
2.0 |
3.0 |
1.0 |
1.0 |
3.0 |
3.0 |
4.0 |
1.0 |
1.0 |
4.0 |
4.0 |
2.0 |
1.0 |
0.5 |
2.0 |
1.0 |
3.0 |
1.0 |
0.5 |
3.0 |
1.5 |
4.0 |
1.0 |
0.5 |
4.0 |
2.0 |
2.0 |
1.0 |
0.3 |
2.0 |
0.6 |
3.0 |
1.0 |
0.3 |
3.0 |
0.9 |
4.0 |
1.0 |
0.3 |
4.0 |
1.2 |
We're sure your any inquiry will get prompt attention !
