Home > Industrial Equipment & Components > Ventilation Equipment > Blowers > Variable Speed Duct Fan

Variable Speed Duct Fan

Name: Variable Speed Duct Fan
Brand: HCSINO or OEM
SKU: 118882489

US$ 1 - 75 MOQ: 50 Pieces

Key Specifications

Get Latest Price

Electric Current Type:

Blade Material:

Plastic

Mounting:

Duct Fan

Contact Supplier Request Quote Chat Now

Hangzhou Huichuang Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Electric Current Type AC

Blade Material Plastic

Mounting Duct Fan

Place of Origin Zhejiang, China

Brand Name HCSINO or OEM

Model Number HCEU-IEC-D

Power 68~380W

Voltage 110~250V

Air Volume 175~1900M3/H

Speed 2250~2750R/MIN, two speed control

Certification CE

Specifications

Variable Speed Duct Fan
1.High quality molded impeller
2.Thermally protected AC motor
3.Includes mounting bracket

Variable Speed Duct Fan

Model: HCEU-IEC-D

We are one of the biggest and professinal manufacturer of ventilation products including FAN, SPEED CONTROLLER, CARBON FILTER, AIR DIFFUSERS, PIPE FITTING, ETC in China. We can provide you with high quality & competitive price & excellent service. Welcome to visit our Group Company at any time.

DETAILS

Typical sizes available: Ø100; Ø125; Ø150; Ø160; Ø200; Ø250; Ø305,Ø315

Colour available: Black, White

It is used to transmit and strengthen the air flow inside a network of ventilation systems.

The Plastic Inline Duct Fan is equipped with ball bearing and visible propeller with a protective grate. The installations can be mounted horizontally and vertically.

The propeller blades are directed backwards, ensuring higher pressure and work effciency.

The casing is made from Plastic (ABS) and the fan sat included fixings for a secure installation.

TECHNICAL PARAMETER

Model	Voltage	Frequency	Power	Rotate	Air Flow	Pressure
(HCEU-DIR)	(V )	(HZ)	(W)	(R/Min)	(M3/H)	(Pa)
Φ100mm	120 / 230	60 / 50	69	2590	175 / 350	360
Φ125mm	120 / 230	60 / 50	71	2535	220 / 440	390
Φ150mm	120 / 230	60 / 50	100	2350	305 / 610	430
Φ160mm	120 / 230	60 / 50	130	2580	350 / 700	475
Φ200mm	120 / 230	60 / 50	190	2150	525 / 1050	620
Φ250mm	120 / 230	60 / 50	195	2250	600 / 1200	635
Φ305mm	120 / 230	60 / 50	245	2450	925 / 1850	690
Φ315mm	120 / 230	60 / 50	250	2520	950 / 1900	720
